Structural Steel Shop Drawings – GM Maintenance Platform
Prepared a detailed structural steel shop drawing package for an industrial maintenance platform system, including fabrication-ready beam, plate, ladder, and connection detailing for steel manufacturing and assembly coordination. The project involved precision drafting for multiple custom steel components using S275 and S235 structural steel profiles with detailed hole layouts, weld preparation geometry, and assembly references.
Scope of work included:
• Steel fabrication and shop drawings
• Beam, plate, and ladder detailing
• Hole layout and bolt coordination
• Structural steel member sizing and labeling
• Fabrication dimensions and cutting geometry
• Assembly allocation schedules and quantity coordination
• Connection detailing for industrial steel platform systems
• Production-ready drawings for workshop and site installation
