Integrated Design For Manufacturing & AR-Aided Assembly

Ryan Hughes

Product Designer
Mathematician
Software Engineer
C#
CAD
Grasshopper
Hochschule für nachhaltige Entwicklung Eberswalde





Introduction

This paper presents a novel workflow for the design, robotic fabrication & assembly of lightweight complex timber structures based on a reciprocal frame structural principle. The described method expands existing research in the field by demonstrating a unified mesh-based workflow throughout the form-finding, manufacturing and assembly phases, as well as applications of Augmented Reality (AR) at several process stages.

A case study in the design and construction of a prototypical self-supporting lightweight timber structure is presented. The process illustrates the dynamic transfer of data between various design, analysis and manufacturing simulation environments through the use of a common lightweight skeletal model and a Just-In-Time (JIT) approach to manufacturing geometry creation. As such, the method serves as an example of Fabrication Information Modelling (FIM), an approach characterized by the synthesis of multiscale, interdisciplinary geometric representations, material properties, and fabrication parameters.





Code Availability

The Axis Robot Control Framework (RCF)is accessible to the public at github.com/AxisArch/ as well as axisarch.tech/framework. We currently support the online and offline control of ABB and KUKA robots as well as experimental features for UR. We encourage others to leave feedback or contribute to the project. Sample files for the geometry generation and robot control setup are available upon request.

Acknowledgements

The authors would like to thank Aarhus School of Architecture and Paramateria for their invitations to teach workshops as part of their educational programs, through which the prototype was made possible, as well as HNE Eberswalde and Ligas Berlin for their generous support in hosting and financing the prototype construction. Additionally, we would like to thank Tassilo Goldmann and Tim Peters for their material knowledge and assistance in production.

Publication Information

Authors & Affiliations

  1. Ryan Hughes & Niels Martin Larsen - Aarhus School of Architecture, Noerreport 20, 8000, Aarhus, Denmark
  2. Toni Osterlund - Geometria Architecture Ltd, Tehtaankatu 29 A, 00150, Helsinki, Finland

Citations

Hughes, R., Osterlund, T. & Larsen, N.M. Integrated design-for-manufacturing and AR-aided-assembly workflows for lightweight reciprocal frame timber structures. Constr Robot 5, 147–157 (2021). https://doi.org/10.1007/s41693-020-00048-3

Download citation

  • Received 12 June 2020
  • Accepted 05 November 2020
  • Published 26 June 2021
  • Issue Date June 2021
  • DOI https://doi.org/10.1007/s41693-020-00048-3
