Luis Sanchez
Mechanical Engineer | Sheet Metal & Structures | Solidworks
New to Contra
Luis is ready for their next project!
This project was for developing the Manufacturing Drawings for these Sheet Metal Workstations.
The project had 2 Stages; the first one was for 3D Modeling. And the second stage was for the 2D Manufacturing Drawings, but we never complete this stage.
I've used SolidWorks for 3D...
CHALLENGE:
Design a Shipping container that has a standard pallet dimension footprint (1.0x1.2 m). The shipping container has to be stackable and support approximately 1080 lbs.
SOLUTION:
Use Frame Generator to get an accurate BOM.
Use the Sheet Metal Feature to get an...
CHALLENGE:
Design for Manufacturing a Chassis frame for a wheeled seed dispensing tool. The design should prioritize simplicity, cost, and ease of shipping and assembly, while still being durable for outdoor use on uneven field terrain and providing basic shock/vibration...
CHALLENGE:
Design a fully engineered CAD model and manufacturable prototype for a portable power-assist device that inserts into the 1.5” inner diameter winch shaft on standard flatbed trailer winches and automatically tightens/releases cargo straps.
SOLUTION:
Expandable Steel...
CHALLENGE:
The goal of this project is to integrate the racks of amplifiers and other equipment used for the speaker systems at a concert. This new rack setup will allow equipment to be installed in the shop and re-used many times without modification or re-wiring, minimizing...
