Document Workflow Core – Lifecycle & Audit Backend Demo
crystal zhu
Document Workflow Core – Lifecycle & Audit-Driven Backend Demo
What this demo models
This demo models a document-centric backend workflow where a business document must pass through a controlled lifecycle before reaching a final state.
The focus is not on UI polish but on backend structure, rules, and safety — the kind required in approval flows, compliance systems, and external integrations.
Domain core: Document
At the center of the system is a Document as a domain entity, not a database record.
Each document:
Has a clearly defined lifecycle
Enforces valid state transitions
Records who can act on it, and when
Produces an audit trail for every meaningful change
This makes the system predictable and safe to extend.
Lifecycle & state machine
The document follows a strict lifecycle, for example:
DRAFT → SUBMITTED → UNDER_REVIEW → APPROVED / REJECTED → ARCHIVED
State transitions are:
Explicit
Validated on the backend
Not bypassable by UI or API misuse
Roles bound to states
Actions are bound to roles and states, not endpoints.
For example:
A creator can submit a draft
A reviewer can move a document into review or request changes
An approver can make the final decision
This prevents invalid operations and keeps business rules centralized.
Audit as a first-class concept
Every lifecycle action produces an audit log entry:
Who performed the action
From which state to which state
Optional reason or note
This makes the system traceable, debuggable, and safe to evolve over time.
Why this matters
This structure is common in:
Approval workflows
Financial or accounting systems
Compliance-driven platforms
Backend integrations with external systems
The demo is designed to show how complex business rules can be enforced cleanly on the backend, independent of UI or transport layer.
GitHub: 👇
Like this project
Posted Jan 29, 2026
Backend demo showcasing a document lifecycle with enforced state transitions, role-based permissions, and audit logs.
