Summary:
The CN-Seamless Mach 1 is a metal fabricator's dream come true. The innovative product merges precision robotics with portability, helping reshape industry production. Equipped with an oxy-fuel attachment, craftsmen can effortlessly shape steel up to 12" thick. The Mach 1 features a swift setup time of under 5 minutes and an intuitive interface that mirrors familiar cutting methods. Its compact build enables easy transport and storage, making it an ideal companion for any work site. Will Breen collaborated with the three founders of CN-Seamless to strategize, plan, design, and develop a user-friendly touchscreen interface for controlling the CN-Seamless Mach 1.

Creating and editing shapes before a cut

Touchscreen design preview (working sample)
Challenge
The founding team recognized the need for assistance with designing and developing the Human-Machine Interface (HMI) essential for controlling their machine. Upon joining the team, we discovered that the challenge included a basic UI prototype for machine control that lacked the intuitive features characteristic of a traditional professional HMI. It became evident that users without specific training would struggle with the current interface, prompting the development of an initial software version before rolling it out to eagerly awaiting new customers.

UX Journey mapping (early preview)

All NAV designs
Result
From concept to a fully-fledged HMI, the project took around eight to ten weeks, a rapid timeline given the complexity of integrating the UI with the machinery. As highlighted in previous articles, speed is the key to a successful project and startup. Will Breen diligently crafted an intuitive user experience, enabling the company to advance in client delivery and future sales, accelerating the product's market entry.

Editing cutting tip sizing

Paused menu to move the cut while in progress

Editing the orientation of the machine
0 likes · 31 views · Aug 26, 2024
I collaborated with the CN-Seamless team to strategize, plan, design, and develop a user-friendly touchscreen interface for controlling their machine.
