Interactive Visualization of NHS Satisfaction Trends

About the data/article in a nutshell: Tom uses a combination of sources to make his point → while not a bottom ‘performer’; especially compared to the US, UK’s National Health Service (NHS) did not wait for the COVID crisis to show its limits and harbor increasing consumer dissatisfaction. That downward trend can be traced back to the early 2010’s; and that comes from the service running lean - too lean - but also inefficiently, For more detail on the sources, feel free to visit the actual article with link embedded at the top of the page in the author’s name. If you like to download the data, feel free to use urls here.

Overall Strategy for building first plot: The data for first plot is smoothed out/interpolated data; this is usually done to ‘well smooth’ the data and delineate clearer trends over time; in this case select European countries’ survey takers’ scores on their overall satisfaction level towards their respective countries’ public health services (ESS - European Social Survey). In this case, there is an additional reason the author smoothed the data; it is to ‘complete’ the years given that the ESS is done once every two years; note that I am assuming here but it’s not an outrageous assumption to make. So in order to match that smoothing, I go with geom_smooth() from ggplot2 and keep span at default; after a few iterations; the data points (for non survey years) match highly to what Tom displays in the first graph. Finally, since the graph is interactive, I use ggiraph package to emulate said interactivity; a JS based R package that lets you add tooltips/hover/highlight upon hover/downplay non-hovered, etc. all the usual things one expects from an interactive plot; without having to build a Shiny app; which for this exercise/first plot (and the rest); would be like building a Gatling gun to aim at an ant.

Steps taken: While I try to be as detailed in my comments as possible; it’s still helpful to lay out the step by step process as a numbered list to get the overall chain of what the code is supposed to do on a high level - without having to go into the nitty gritty- the comments in the code chunks and in that regard should hopefully help:

Found the source of the data from HTML Source Page; clicked on Network tab after hovering on the plot panel; refreshed the page; and found ‘dataset’ under ‘datawrapper’.

The data was wide in structure (from raw csv): 17 columns (1 column for year, 8 hex-coded columns with imputed/smoothed values, and 8 columns for country abbreviations with survey data for even years, NULL otherwise).

Discovered the hex columns and country columns didn’t align in a straightforward way. Columns were randomly ordered within each set, requiring a ranking approach rather than pairwise matching (one hex column to the symmetrical position of the country labeled column).

Implemented a solution by sorting satisfaction scores per year, which helped group values by country through proximity of their scores. This approach works well since the values are interpolated through smoothing, making them very close to one another from row to row. This might not work in other cases, but it does here.

Combined two sorted datasets: year + hex columns, and year + country columns to create a properly aligned mapping, joined facts data (with scores/values) on newly created mapped long datasets (converted from wide- almost always much harder to work with) to then finalize the dataset for visualization. More detail on ‘finalized the dataset’ can be found in the comments of the actual code. Prepared the final clean dataset for interactive plotting with ggiraph.
