General Product Design & Engineering
Victor Red
The client asked for the design of hydraulic scissors to recycle material, in this case the client had a very specific idea with the thickness of the material and the color.With my deliverables, the client was able to know the exact volume, weight, and usability of the product and calculate the approximate quantity and cost of the materials.From start to finish, I helped them generate 3d renders showing all views, size and dimensional references, technical drawings for production, exploded views for assemblies and part listings.
Simple Isometric View
Like this project
Posted Apr 8, 2023
Part designs, entire Assembly designs, Part & assembly technical drawings, movement & collision analysis, dimensional & weight analysis.
