Cover image for From red and blue traces
From red and blue traces on a screen to a fully fabricated PCB - the hardware design process is always exciting. But the greatest reward is seeing the final product in action. Hearing scientists use my boards alongside their high-grade lab equipment makes all the hard work completely worthwhile.
2
5
260
Cover image for Inline 1 to 2 CAN
Inline 1 to 2 CAN Bus router. Self contained, inline potted router flashed for a specific piece of hardware translating abstracted message to hardware specific messages and signals.
1
113
Cover image for Water quality logger for divers
Water quality logger for divers
1
180
Cover image for The CANaBUS ADC Carrier is
The CANaBUS ADC Carrier is a specialized ROS2 edge board designed as an Ethernet and UART carrier for the Jrk G2 18v27 USB Motor Controller. Powered by the Teensy 4.1, it provides high-speed processing and seamless integration for closed-loop motor control with feedback. 🛠️ Key Technical Features Controller Interface: Specifically designed to host and communicate with the Jrk G2 18v27 via dedicated UART channels (UART1/UART2) for precise motor commands. Ethernet Connectivity: Integrated RJ45 MagJack (J1B1211CCD) provides native 10/100 Mbps Ethernet for high-reliability ROS2 data streaming. 4-Channel ADC: Features four dedicated analog-to-digital converter channels accessible via Teensy pins, ideal for monitoring real-time sensor feedback or voltage differentials.
1
227
