Async Trading Bot Development for Binance and Coinbase by Carlos RodriguezAsync Trading Bot Development for Binance and Coinbase by Carlos Rodriguez

Async Trading Bot Development for Binance and Coinbase

Carlos Rodriguez

Automation Engineer

DevOps Engineer

Fullstack Engineer

Docker

Python

React

Investment & Asset Management

API Trading Bot

A high-performance, async trading bot built with Sanic, supporting automated trading on Binance and Coinbase. The bot uses predefined strategies (e.g., MACD) to analyze market data, execute trades, and manage positions, with extensibility for adding new exchanges and strategies.

Features

Exchanges: Binance (live/testnet) and Coinbase (live/sandbox) support.

Strategies: Modular strategy system with a sample MACD implementation.

API Endpoints: Manage balances, orders, positions, strategies, and bot lifecycle.

Async Architecture: Built on Sanic for non-blocking performance.

Dockerized: Containerized deployment with TA-Lib support.

Testing: Comprehensive pytest suite for utilities and strategies.

Prerequisites

Python: 3.11+

Docker: For containerized deployment.

API Keys:

Binance: Live (BINANCE_API_KEY, BINANCE_API_SECRET) and Testnet (BINANCE_TESTNET_API_KEY, BINANCE_TESTNET_API_SECRET).

Coinbase: Live (COINBASE_API_KEY, COINBASE_API_SECRET, COINBASE_PASSPHRASE) and Sandbox (COINBASE_SANDBOX_API_KEY, COINBASE_SANDBOX_API_SECRET, COINBASE_SANDBOX_PASSPHRASE).

Setup

Local Development

Clone the Repository:

   git clone https://github.com/yourusername/api-trading-bot.git
   cd api-trading-bot

Create a Virtual Environment:

python -m venv .venv
source .venv/bin/activate  # On Windows: .venv\Scripts\activate

Install Dependencies:

pip install -r requirements.txt

Ensure libta-lib0 is installed for TA-Lib:

sudo apt-get update && sudo apt-get install -y libta-lib0  # Debian/Ubuntu

Configure Environment Variables:

Create a .env file in the root directory:

BINANCE_API_KEY=your_live_key BINANCE_API_SECRET=your_live_secret BINANCE_TESTNET_API_KEY=your_testnet_key BINANCE_TESTNET_API_SECRET=your_testnet_secret COINBASE_API_KEY=your_live_key COINBASE_API_SECRET=your_live_secret COINBASE_PASSPHRASE=your_live_passphrase COINBASE_SANDBOX_API_KEY=your_sandbox_key COINBASE_SANDBOX_API_SECRET=your_sandbox_secret COINBASE_SANDBOX_PASSPHRASE=your_sandbox_passphrase DEBUG=false WORKERS=4 PORT=8000

Run the Backend:

python app/main.py

Access the API at http://localhost:8000/

Run the Frontend (optional):

cd binance-trading-dashboard
npm install
npm start

Access the dashboard at http://localhost:3000/

Docker Deployment

Backend Only

Build the Backend Docker Image:

docker build -t trading-bot-backend .

Run the Backend Container:

docker run -p 8000:8000 --env-file .env trading-bot-backend

Optionally override env vars:

docker run -p 8000:8000 -e PORT=8080 --env-file .env trading-bot-backend

Full Stack Deployment with Docker Compose

For deploying both the backend and frontend together:

Ensure you have a .env file in the root directory with your credentials:

BINANCE_API_KEY=your_api_key_here
BINANCE_API_SECRET=your_api_secret_here

Build and start both containers using Docker Compose:

docker-compose up -d

Access the application:

Frontend Dashboard: http://localhost

Backend API: http://localhost:8000

Stop the containers:

docker-compose down

Usage

API Endpoints

Balance:

GET /api/v1/balance/overall?exchange=binance: Total USD balance.

GET /api/v1/balance/coins?exchange=coinbase: Coin-specific balances.

Orders:

POST /api/v1/order/buy: Create a buy order.

{
  "coinPair": "BTCUSDT",
  "quantity": 0.001,
  "price": 50000,
  "exchange": "binance"
}

POST /api/v1/order/sell: Create a sell order.

POST /api/v1/order/exit: Exit a position.

Positions:

GET /api/v1/positions/open?exchange=binance: Open positions.

GET /api/v1/positions/closed?exchange=coinbase: Closed positions.

Strategy:

POST /api/v1/strategy/: Select a strategy.

{"strategyName": "macd_strategy"}

* POST /api/v1/strategy/parameters: Set strategy params.
* GET /api/v1/strategy/list: List available strategies.
* GET /api/v1/strategy/indicators: List TA-Lib indicators.

Bot Control:
* POST /api/v1/bot/start: Start the bot.
```json
{"strategyName": "macd_strategy", "coinPair": "BTCUSDT", "exchange": "binance"}

POST /api/v1/bot/stop: Stop the bot.

{ "exchange": "binance" }

Headers: All endpoints require X-MBX-APIKEY with a valid API key.

Example Request

curl -X POST -H "X-MBX-APIKEY: your_testnet_key" -d '{"coinPair":"BTCUSDT","quantity":0.001,"price":50000,"exchange":"binance"}' http://localhost:8000/api/v1/order/buy

Testing

Run the test suite with pytest:

pytest tests/ -v

Requirements: pytest, pytest-asyncio (in requirements.txt). Tests: test_binance_utils.py: Binance Testnet functionality. test_coinbase_utils.py: Coinbase Sandbox functionality. test_strategies.py: MACD strategy logic. test_connection.py: Basic Binance connectivity.

Ensure .env is configured with test credentials.

User Interface Showcase

The trading dashboard features a modern, responsive UI designed for optimal trading experience.

Login Page

Dashboard Overview

Market Data Analysis

Position Management

Active Bot Control

Trading Interface

Strategy Configuration

System Settings

Project Structure

API-Trading-Bot/ ├── app/ │ ├── api/ # API endpoints │ ├── strategies/ # Trading strategies │ ├── utils/ # Exchange utilities │ ├── config.py # Configuration │ ├── main.py # App entry point ├── binance-trading-dashboard/ # React frontend application │ ├── public/ │ ├── src/ │ │ ├── components/ # UI components │ │ ├── contexts/ # React contexts │ │ ├── layouts/ # Page layouts │ │ ├── pages/ # Application pages │ │ ├── services/ # API services │ │ ├── utils/ # Utility functions │ ├── Dockerfile # Frontend Docker configuration │ ├── nginx.conf # Nginx configuration for the frontend │ ├── package.json # Frontend dependencies ├── images/ # UI screenshots ├── tests/ # Test suite ├── Dockerfile # Backend Docker configuration ├── docker-compose.yml # Full stack Docker configuration ├── requirements.txt # Backend dependencies ├── .env # Environment variables (not tracked) └── README.md # This file

Contributing

Fork the repository. Create a feature branch (git checkout -b feature/your-feature). Commit changes (git commit -m "Add your feature"). Push to the branch (git push origin feature/your-feature). Open a pull request.

License

This project is licensed under the MIT License—see LICENSE for details.

Acknowledgments

Built with Sanic, python-binance, and cbpro. TA-Lib for technical analysis.
