Real-Time AI Avatar Backend and Frontend integration Development

Akashdeep via Replit

Completed work

AI Engineer

FastAPI

Python

React

Artificial Intelligence

AI Avatar

This project is a real-time AI avatar that can listen, think, and respond to users. It is built with a Python backend using FastAPI and a React frontend. The avatar is powered by a combination of Automatic Speech Recognition (ASR), Large Language Models (LLM), and Text-to-Speech (TTS) technologies.

Features

Real-time Interaction: The AI avatar can listen and respond to users in real-time.

Live2D Integration: The avatar is rendered using Live2D, which allows for expressive and dynamic animations.

Modular Architecture: The application is designed with a modular architecture that allows for easy extension and customization.

Configurable ASR and TTS: The ASR and TTS engines can be easily configured through environment variables.

Audio Processing: The application includes a configurable audio processing pipeline that can be used to improve ASR accuracy.

React Component: The frontend is built as a reusable React component that can be easily integrated into other applications.

Architecture

The application is composed of a Python backend and a React frontend.

Backend

The backend is built with FastAPI and is responsible for:

WebSocket Communication: The backend uses WebSockets to communicate with the frontend in real-time.

ASR, LLM, and TTS Integration: The backend integrates with ASR, LLM, and TTS engines to power the AI avatar.

Audio Processing: The backend includes an audio processing pipeline that can be used to improve ASR accuracy.

Frontend

The frontend is built with React and is responsible for:

Rendering the Avatar: The frontend uses the Live2D SDK to render the AI avatar.

User Interaction: The frontend captures audio from the user's microphone and sends it to the backend for processing.

Displaying Responses: The frontend displays the AI avatar's responses and animations.

Getting Started

To get started with the project, you will need to have Python and Node.js installed on your system.

Backend Setup

Clone the repository:

git clone https://github.com/your-username/ai-avatar.git
cd ai-avatar

Create a virtual environment:

python -m venv .venv
source .venv/bin/activate

Install the dependencies:

pip install -r requirements.txt

Create a .env file:

cp .env.example .env

Run the backend:

python3 main.py

Frontend Setup

Navigate to the frontend directory:

cd frontend

Install the dependencies:

npm install

Setup the environment variables:

cp .env.example .env

Run the frontend:

npm run dev

Configuration

The application can be configured through environment variables. The available options are documented in the .env.example file.

LLM Settings

LLM_ENGINE: The LLM engine to use. Options: open_router, google_gemini.

LLM_MODEL: The LLM model to use.

OPENROUTER_API_KEY: Your OpenRouter API key.

GEMINI_API_KEY: Your Google Gemini API key.

ASR Settings

ASR_ENGINE: The ASR engine to use. Options: sherpa_onnx_asr, faster_whisper_asr.

ASR_DEVICE: The device to use for ASR inference. Options: cpu, cuda.

ASR_MODEL: The ASR model to use.

ASR_COMPUTE_TYPE: The compute type for ASR. Options: int8, fp16, fp32.

ASR_CPU_THREADS: The number of CPU threads for ASR.

TTS Settings

CHATTERBOX_TTS_BASE_URL: The base URL for the Chatterbox TTS service.

CHATTERBOX_TTS_API_KEY: The API key for the Chatterbox TTS service.

App Settings

APP_ALLOWED_ORIGINS: The allowed origins for CORS.

APP_DEBUG_SAVE_AUDIO: Save original and normalized audio for debugging.

APP_ENABLE_AUDIO_PROCESSING: Enable audio processing.

APP_NOISE_REDUCTION: Enable noise reduction.

APP_LOUDNESS_NORMALIZATION: Enable loudness normalization.

Characters

Characters are defined in .yaml files in the characters directory. Each character has a unique persona, Live2D model, and TTS engine.

Creating a New Character

To create a new character, you will need to:

Add a Live2D Model: Add the character's Live2D model to the live2d-models directory.

Create a YAML File: Create a new .yaml file in the characters directory.

Configure the Character: Configure the character's name, persona, Live2D model, and TTS engine in the YAML file.

Character Configuration

The following options are available for configuring a character:

name: The name of the character.

llm_persona: The character's persona.

live2d_model_name: The name of the character's Live2D model.

tts_engine: The TTS engine to use for the character.

Live2D Models

Live2D models are defined in the model_dict.json file. Each model has a unique name, description, and URL.

Adding a New Live2D Model

To add a new Live2D model, you will need to:

Add the Model Files: Add the model's files to the live2d-models directory.

Update model_dict.json: Add a new entry to the model_dict.json file with the model's name, description, and URL.

Model Configuration

The following options are available for configuring a Live2D model in model_dict.json:

name: The name of the model.

description: A description of the model.

url: The URL of the model's .model3.json file.

kScale: The scale of the model.

initialXshift: The initial X shift of the model.

initialYshift: The initial Y shift of the model.

kXOffset: The X offset of the model.

idleMotionGroupName: The name of the idle motion group.

emotionMap: A map of emotions to expression files.

motionMap: A map of motions to motion files.

tapMotions: A map of tap motions to motion files.

Integration Guide

The AI Avatar can be easily integrated into any React application.

For more advanced usage examples, please refer to the files in the frontend/src/examples directory.

1. Copy the `AIAvatar` Component

Copy the frontend/src/components/AIAvatar directory to your React application's src/components directory.

2. Install the Dependencies

Install the following dependencies in your React application:

npm install @ricky0123/vad-react

3. Use the `AIAvatarProvider` and `AIAvatarCanvas`

Wrap your application with the AIAvatarProvider and use the AIAvatarCanvas to render the avatar.

import React from "react";
import { AIAvatarProvider, AIAvatarCanvas } from "./components/AIAvatar";

function App() {
  return (
    <AIAvatarProvider backendUrl="http://localhost:8000">
      <AIAvatarCanvas />
    </AIAvatarProvider>
  );
}

export default App;

4. Use the `useAIAvatar` Hook

Use the useAIAvatar hook to interact with the AI avatar.

import React from "react";
import { useAIAvatar } from "./components/AIAvatar";

function MyComponent() {
  const {
    sendText,
    startRecording,
    stopRecording,
    connect,
    fetchCharacters,
    selectCharacter,
    characters,
  } = useAIAvatar();

  React.useEffect(() => {
    connect();
    fetchCharacters();
  }, [connect, fetchCharacters]);

  React.useEffect(() => {
    if (characters.length > 0) {
      selectCharacter(characters[0].id);
    }
  }, [characters, selectCharacter]);

  return (
    <div>
      <button onClick={() => sendText("Hello, world!")}>Send Text</button>
      <button onClick={startRecording}>Start Recording</button>
      <button onClick={stopRecording}>Stop Recording</button>
    </div>
  );
}
