Chatterbox TTS

Chatterbox TTS is a high-performance, containerized Text-to-Speech (TTS) service designed for real-time audio generation and streaming. It supports custom voice cloning and is optimized for deployment on GPU-accelerated platforms like RunPod.

Project Overview

This project provides a flexible and scalable solution for generating speech from text. It exposes a robust RESTful API for real-time streaming and is built for stable, concurrent request handling in a production environment.

High-Level Architecture

The service is built on a decoupled master-worker architecture that separates the public-facing API from the resource-intensive TTS processing. This design ensures stability, scalability, and efficient resource utilization.

Master Process (main.py): A single FastAPI application serves as the entry point for all HTTP requests. It handles API logic, authentication, and voice management. Instead of performing TTS tasks itself, it dispatches them to the worker pool via a ZeroMQ message queue.

Worker Processes (worker.py): For each available GPU (or for the CPU if no GPUs are present), a dedicated pool of worker processes is spawned. Each worker initializes its own TTS engine, loads the models onto its assigned device, and listens for jobs from the master.

Inter-Process Communication (IPC) with ZeroMQ: Communication between the master and workers is handled by ZeroMQ, a high-performance messaging library. This ensures reliable, non-blocking data exchange:

Job Queue (PUSH/PULL): The master pushes TTS requests to a central queue, and idle workers pull jobs from it.

Result Channel (PUSH/PULL): Workers push the resulting audio chunks back to the master, which then streams them to the client.

Broadcast Channel (PUB/SUB): The master sends control commands (e.g., to warm up a new voice's cache or cancel a request) to all workers simultaneously.

This architecture allows the API to remain highly responsive while the workers independently handle the heavy lifting of audio generation.

graph TD
    subgraph "Client"
        A[User Application / Web UI]
    end

    subgraph "Master Process (FastAPI)"
        API[FastAPI App]
        VM[Voice Manager]
        ZMQ_Master[ZeroMQ Sockets]
        API -- Manages --> VM
        API -- Uses --> ZMQ_Master
    end

    subgraph "Inter-Process Communication (ZeroMQ)"
        JobQ[(Job Queue PUSH/PULL)]
        ResultQ[(Result Queue PUSH/PULL)]
        BroadcastQ[(Broadcast PUB/SUB)]
    end

    subgraph "Worker Processes"
        subgraph "Worker 0"
            W0[TTS Engine]
        end
        subgraph "Worker 1"
            W1[TTS Engine]
        end
        subgraph "Worker N"
            WN[TTS Engine]
        end
    end

    subgraph "Hardware Resources"
        G0[GPU 0]
        G1[GPU 1]
        GN[GPU N]
        H[Persistent Volume for Voices]
    end

    A -- "HTTP Request" --> API
    API -- "Dispatches Job" --> JobQ
    JobQ -- "Pulls Job" --> W0 & W1 & WN

    W0 & W1 & WN -- "Pushes Result" --> ResultQ
    ResultQ -- "Streams to Client" --> API

    API -- "Broadcasts Command" --> BroadcastQ
    BroadcastQ -- "Subscribes" --> W0 & W1 & WN

    W0 -- "Runs on" --> G0
    W1 -- "Runs on" --> G1
    WN -- "Runs on" --> GN
    VM -- "Load/Save Voices" --> H

    style G0 fill:#ccf,stroke:#333,stroke-width:2px
    style G1 fill:#ccf,stroke:#333,stroke-width:2px
    style GN fill:#ccf,stroke:#333,stroke-width:2px
    style H fill:#cfc,stroke:#333,stroke-width:2px
    style JobQ fill:#f9f,stroke:#333,stroke-width:2px
    style ResultQ fill:#f9f,stroke:#333,stroke-width:2px
    style BroadcastQ fill:#f9f,stroke:#333,stroke-width:2px

Prerequisites

To run this project, you will need:

Docker: The application is containerized and requires Docker to be installed.

GPU: A CUDA-enabled GPU is necessary for the TTS model to perform efficiently.

Configuration

Configuration is managed via environment variables. You can set them in your shell or create a .env file in the project root.

Core Application Settings

Variable Description Default API_KEY (Required) Your secret API key for securing the service. None HOST The host address for the application server. 0.0.0.0 PORT The port for the application server. 8000 DEBUG Enable debug mode. False LOG_LEVEL The logging level (e.g., INFO, DEBUG). INFO WORKERS_PER_DEVICE Number of worker processes to spawn per detected GPU or CPU device. 1 CONCURRENT_REQUESTS_PER_WORKER Maximum number of concurrent TTS requests to process per worker. 1 VOICES_DIR Directory where custom voices are stored. voices/ PRELOADED_VOICES_DIR Directory for preloaded voices. preloaded-voices/ MODEL_PATH Path to the directory containing TTS models. models CORS_ORIGINS A comma-separated list of allowed origins (e.g., "http://localhost:3000,https://your-frontend.com"). *

TTS Engine Tuning

These parameters control the TTS engine's behavior and can be set via environment variables prefixed with TTS_.

Variable Description Default TTS_VOICE_EXAGGERATION_FACTOR Controls the expressiveness of the voice. 0.5 TTS_CFG_GUIDANCE_WEIGHT Influences how strongly the model adheres to the text prompt. 0.5 TTS_SYNTHESIS_TEMPERATURE Controls the randomness of the output. 0.8 TTS_TEXT_PROCESSING_CHUNK_SIZE Max characters per text chunk. Smaller values can reduce latency. 150 TTS_AUDIO_TOKENS_PER_SLICE Number of audio tokens per slice during streaming. Affects granularity. 35 TTS_REMOVE_LEADING_MILLISECONDS Milliseconds to trim from the start of the audio. 0 TTS_REMOVE_TRAILING_MILLISECONDS Milliseconds to trim from the end of the audio. 0 TTS_CHUNK_OVERLAP_STRATEGY Strategy for overlapping audio chunks: "full" or "zero". "full" TTS_CROSSFADE_DURATION_MILLISECONDS Duration in milliseconds for crossfading between audio chunks. 30 TTS_SPEECH_TOKEN_QUEUE_MAX_SIZE Buffer size between T3 and S3Gen models. Smaller values (~2) reduce initial latency. 2 TTS_PCM_CHUNK_QUEUE_MAX_SIZE Buffer size for outgoing audio. Smaller values (~3) reduce latency but increase stutter risk. 3

Example `.env` file

# Server Settings
API_KEY="your-super-secret-api-key"
CONCURRENT_REQUESTS_PER_WORKER=2 # Allow 2 TTS tasks per GPU

# TTS Tuning for Low Latency
TTS_SPEECH_TOKEN_QUEUE_MAX_SIZE=2
TTS_PCM_CHUNK_QUEUE_MAX_SIZE=3

Setup and Deployment

1. Build the Docker Image

From the project's root directory, build the Docker image:

docker build -t chatterbox-tts:latest .

2. Run the Docker Container

Run the container, mapping port 8000, providing the environment variables, and mounting a volume for persistent voice storage:

docker run -d -p 8000:8000 \
  --gpus all \
  -v $(pwd)/voices:/app/voices \
  -v $(pwd)/preloaded-voices:/app/preloaded-voices \
  --env-file .env \
  --name chatterbox-tts \
  chatterbox-tts:latest

Docker Hub and GitHub Actions

Using the Pre-built Docker Image

Instead of building the Docker image locally, you can use the pre-built image from Docker Hub, which is automatically updated with the latest changes.

Pull the Image

docker pull akashdeep000/chatterbox-tts:latest

Run the Container

Use the pulled image to run the container:

docker run -d -p 8000:8000 \
  --gpus all \
  -v $(pwd)/voices:/app/voices \
  -v $(pwd)/preloaded-voices:/app/preloaded-voices \
  --env-file .env \
  --name chatterbox-tts \
  akashdeep000/chatterbox-tts:latest

Note: If you are using a GPU, you may need to add --gpus all to the docker run command.

Automated Builds with GitHub Actions

This repository uses GitHub Actions to automate the building and publishing of the Docker image to Docker Hub. On every push, a new image is built and tagged with latest and the commit SHA.

You can view the workflow configuration at .github/workflows/publish-docker.yml.

Setup

To enable the workflow to publish to your Docker Hub account, you need to configure the following repository secrets and variables in your GitHub repository settings:

DOCKERHUB_USERNAME:

Type: Variable

Value: Your Docker Hub username.

Go to Settings > Secrets and variables > Actions > Variables and add a new repository variable.

DOCKERHUB_TOKEN:

Type: Secret

Value: Your Docker Hub access token. You can generate one in your Docker Hub account settings.

Go to Settings > Secrets and variables > Actions > Secrets and add a new repository secret.

API Usage

System Status: `GET /system-status`

Provides real-time CPU, RAM, and GPU utilization details. Useful for monitoring the health and load of the service.

Example with curl:

curl -X GET -H "X-API-Key: <YOUR_API_KEY>" http://localhost:8000/system-status

Example Response:

{
  "cpu": {
    "utilization_percent": 25.8,
    "ram_gb": {
      "total": 31.26,
      "used": 8.94,
      "free": 22.32,
      "percent_used": 28.6
    }
  },
  "gpus": [
    {
      "device_id": 0,
      "utilization_percent": { "gpu": 45, "memory": 28 },
      "memory_gb": { "total": 15.75, "used": 3.15, "free": 12.6 }
    },
    {
      "device_id": 1,
      "utilization_percent": { "gpu": 10, "memory": 15 },
      "memory_gb": { "total": 15.75, "used": 1.5, "free": 14.25 }
    }
  ]
}

TTS Generation: `/tts/generate`

This endpoint generates and streams audio in real-time. It supports both GET and POST requests, providing flexibility for different use cases.

Authentication

For all requests to this endpoint, the API key can be provided in one of two ways:

Header: X-API-Key: <YOUR_API_KEY>

Query Parameter: ?api_key=<YOUR_API_KEY>

POST Request

This method is suitable for server-to-server communication or when the text is long.

Example with curl:

curl -X POST \
  -H "Content-Type: application/json" \
  -H "X-API-Key: <YOUR_API_KEY>" \
  -d '{"text": "Hello, this is a custom voice.", "voice_id": "your_voice.wav"}' \
  http://localhost:8000/tts/generate --output custom_voice_output.wav

GET Request

This method is ideal for use in web browsers, as it allows you to set the endpoint URL directly as the src of an <audio> tag.

Example with curl:

curl -X GET "http://localhost:8000/tts/generate?text=Hello%20world&voice_id=your_voice.wav&api_key=<YOUR_API_KEY>&format=mp3" --output output.mp3

Example in HTML:

<audio
  controls
  src="http://localhost:8000/tts/generate?text=Hello%20world&api_key=<YOUR_API_KEY>&format=mp3"
></audio>

Advanced Usage: Streaming with Media Source Extensions (MSE)

For the lowest latency playback in web applications, you can use the Media Source Extensions (MSE) API to handle the incoming audio stream. This approach gives you fine-grained control over buffering and playback.

The fmp4 (Fragmented MP4) format is recommended for use with MSE.

Example with MSE:

<!DOCTYPE html>
<html lang="en">
  <head>
    <meta charset="UTF-8" />
    <title>MSE Streaming Example</title>
  </head>
  <body>
    <h1>Real-time TTS Streaming with MSE</h1>
    <audio id="audioPlayer" controls></audio>
    <br />
    <input
      type="text"
      id="textInput"
      value="Hello from the world of real-time audio streaming."
    />
    <button id="playButton">Play</button>

    <script>
      const audioPlayer = document.getElementById("audioPlayer");
      const textInput = document.getElementById("textInput");
      const playButton = document.getElementById("playButton");
      const apiKey = "YOUR_API_KEY"; // Replace with your actual API key

      playButton.addEventListener("click", async () => {
        const text = encodeURIComponent(textInput.value);
        const url = `http://localhost:8000/tts/generate?text=${text}&api_key=${apiKey}&format=fmp4`;

        if (
          window.MediaSource &&
          MediaSource.isTypeSupported('audio/mp4; codecs="mp4a.40.2"')
        ) {
          const mediaSource = new MediaSource();
          audioPlayer.src = URL.createObjectURL(mediaSource);

          mediaSource.addEventListener("sourceopen", () => {
            const sourceBuffer = mediaSource.addSourceBuffer(
              'audio/mp4; codecs="mp4a.40.2"'
            );

            fetch(url)
              .then((response) => {
                if (!response.ok) {
                  throw new Error(`HTTP error! status: ${response.status}`);
                }
                const reader = response.body.getReader();

                function push() {
                  reader
                    .read()
                    .then(({ done, value }) => {
                      if (done) {
                        if (!mediaSource.ended) {
                          mediaSource.endOfStream();
                        }
                        return;
                      }
                      sourceBuffer.appendBuffer(value);
                      push();
                    })
                    .catch((err) => {
                      console.error("Error reading stream:", err);
                    });
                }

                sourceBuffer.addEventListener("updateend", push, {
                  once: true,
                });
                push();
              })
              .catch((e) => console.error("Fetch error:", e));
          });

          audioPlayer.play();
        } else {
          console.error("MSE or the required codec is not supported.");
          // Fallback for browsers that don't support MSE
          audioPlayer.src = url;
          audioPlayer.play();
        }
      });
    </script>
  </body>
</html>

TTS Parameters

The /tts/generate endpoint accepts several parameters to customize the audio generation. These can be provided in the query string for GET requests or in the JSON body for POST requests.

Parameter Type Default Value Description text string (Required) The text to be converted to speech. voice_id string None The ID of the custom voice to use (e.g., your_voice.wav). If not provided, a default voice is used. format string wav The desired audio format. Supported values: wav, mp3, fmp4, raw_pcm, webm. Overrides the Accept header. cfg_guidance_weight float TTS_CFG_GUIDANCE_WEIGHT Classifier-Free Guidance weight. Higher values make the speech more closely follow the text, but can reduce naturalness. synthesis_temperature float TTS_SYNTHESIS_TEMPERATURE Controls the randomness of the output. Higher values produce more varied and creative speech, while lower values are more deterministic. text_processing_chunk_size integer TTS_TEXT_PROCESSING_CHUNK_SIZE The number of characters to process in each text chunk. Smaller values can reduce latency but may affect prosody. audio_tokens_per_slice integer TTS_AUDIO_TOKENS_PER_SLICE The number of audio tokens to generate in each slice. This affects the granularity of the streaming output. remove_trailing_milliseconds integer TTS_REMOVE_TRAILING_MILLISECONDS Milliseconds of audio to trim from the end of each generated audio chunk. This is useful for fine-tuning the merging between chunks. remove_leading_milliseconds integer TTS_REMOVE_LEADING_MILLISECONDS Milliseconds of audio to trim from the start of each generated audio chunk. This is useful for fine-tuning the merging between chunks. chunk_overlap_method string TTS_CHUNK_OVERLAP_STRATEGY The method for handling overlapping audio chunks. Can be "full" or "zero". crossfade_duration_milliseconds integer TTS_CROSSFADE_DURATION_MILLISECONDS The duration of the crossfade between audio chunks in milliseconds.

Performance & Architecture Deep Dive

The service is engineered for high throughput and low latency via several key design choices that leverage both multi-processing and advanced asynchronous patterns.

Decoupled Master-Worker Model: The architecture separates the API server (master) from the TTS engines (workers). This prevents slow model inference from blocking the main server, ensuring API endpoints for status checks and voice management remain highly responsive.

ZeroMQ for High-Performance IPC: Instead of relying on HTTP for internal communication, the system uses ZeroMQ for lightweight, high-speed, non-blocking messaging between the master and workers, which is ideal for streaming large volumes of data with low overhead.

True Parallelism with Multi-Processing: By spawning dedicated worker processes for each GPU (or CPU), the system bypasses Python's Global Interpreter Lock (GIL). This allows the computationally intensive TTS models to run in true parallel, maximizing hardware utilization.

Optimized Model Execution with torch.compile: Both the T3 (text-to-token) and S3Gen (token-to-audio) models are compiled using torch.compile in "reduce-overhead" mode. This significantly speeds up inference by optimizing the model's execution graph.

Dedicated Executors for Non-Blocking I/O: CPU-bound tasks like audio encoding/decoding and text tokenization are offloaded to dedicated ThreadPoolExecutors. This prevents these tasks from blocking the main asyncio event loop in both the master and worker processes, leading to smoother operation.

Asynchronous Multi-Stage Streaming Pipeline: The core of the real-time streaming is a sophisticated three-stage producer-consumer pipeline within each worker:

T3 Producer: Generates speech tokens from text chunks.

S3Gen Producer: Converts speech tokens into raw audio (PCM) chunks on the GPU.

PCM Consumer: Converts the GPU audio tensors to PCM byte streams, ready for encoding. This multi-stage approach, connected by asyncio queues, ensures a continuous, non-blocking flow of data from text to audible audio.

Intelligent Caching and Cache Invalidation: All voices are pre-cached at worker startup to eliminate warm-up latency. The master process uses ZeroMQ's broadcast capabilities to instantly notify all workers to update their caches when voices are added or deleted, ensuring consistency without restarts.

Multi-GPU Scalability

The system is designed from the ground up to scale across multiple GPUs. The master process automatically detects all available CUDA-enabled GPUs and spawns a dedicated set of worker processes for each one. This provides several key advantages:

Automatic Resource Utilization: The service will use all GPUs on the machine without any manual configuration, maximizing throughput for demanding workloads.

Workload Distribution: The ZeroMQ job queue naturally distributes TTS requests across all available workers on all GPUs, ensuring an even load distribution.

Isolation: Each worker process is pinned to a specific GPU, preventing resource contention and ensuring stable performance.

Performance Optimizations

The TTS engine is optimized for real-time performance through several mechanisms:

Parameter Tuning for Quality and Speed

The text_processing_chunk_size, audio_tokens_per_slice, and chunk_overlap_method parameters are crucial for balancing audio quality and streaming latency. Understanding how they work together allows you to fine-tune the TTS engine for your specific needs.

text_processing_chunk_size: This parameter determines how the input text is split into smaller pieces. The T3 model processes one chunk at a time.

Smaller values (e.g., 50) lead to lower "time to first audio" because the first chunk is processed faster. However, this can sometimes result in less natural prosody, as the model has less context.

Larger values (e.g., 200) provide more context to the model, which can improve the naturalness of the speech, but it will take longer to receive the first audio chunk.

audio_tokens_per_slice: After the T3 model converts a text chunk into a sequence of speech tokens, this parameter determines how many of those tokens are sent to the S3Gen model at a time to be converted into audio.

Smaller values (e.g., 20) result in smaller, more frequent audio chunks being streamed to the client, which can create a smoother streaming experience.

Larger values (e.g., 50) will result in fewer, larger audio chunks, which can be more efficient but may feel less "real-time."

chunk_overlap_method: This parameter defines how the audio from different text chunks is stitched together.

"full": This method creates a seamless overlap between audio chunks, which generally produces the highest quality audio by avoiding clicks or pauses. It is slightly more computationally intensive.

"zero": This method simply concatenates the audio chunks. It is faster but may occasionally produce audible artifacts at the seams between chunks.

crossfade_duration_milliseconds: This parameter determines the duration of the crossfade between audio chunks.

The following diagram illustrates how these parameters relate to each other in the TTS process:

graph TD
    subgraph "Input Text"
        A["The quick brown fox jumps over the lazy dog."]
    end

    subgraph "Text Chunking (text_processing_chunk_size)"
        B["The quick brown fox..."]
        C["...jumps over the lazy dog."]
    end

    subgraph "T3 Model (Text-to-Tokens)"
        D["[Speech Tokens for Chunk 1]"]
        E["[Speech Tokens for Chunk 2]"]
    end

    subgraph "Token Slicing (audio_tokens_per_slice)"
        F["Slice 1.1"]
        G["Slice 1.2"]
        H["Slice 2.1"]
        I["Slice 2.2"]
    end

    subgraph "S3Gen Model (Tokens-to-Audio)"
        J["Audio for Slice 1.1"]
        K["Audio for Slice 1.2"]
        L["Audio for Slice 2.1"]
        M["Audio for Slice 2.2"]
    end

    subgraph "Output Stream (chunk_overlap_method)"
        N["Final Audio Stream"]
    end

    A -- "split by text_processing_chunk_size" --> B & C
    B --> D
    C --> E
    D -- "split by audio_tokens_per_slice" --> F & G
    E -- "split by audio_tokens_per_slice" --> H & I
    F --> J
    G --> K
    H --> L
    I --> M
    J & K & L & M -- "stitched by chunk_overlap_method" --> N

Aggressive Pre-caching: To eliminate warm-up latency, the service pre-loads all TTS models and pre-caches the conditioning data for all available voices into GPU memory at startup. This ensures that every voice is ready for immediate, high-performance inference from the very first request.

Intelligent Cache Invalidation: The voice cache is automatically and precisely invalidated when a voice is updated or deleted, guaranteeing that the system always uses the most recent voice data without requiring a manual restart.

Asynchronous Streaming Pipeline: The core of the real-time streaming is a highly efficient producer-consumer pattern. The T3 model (producer) generates speech tokens concurrently while the S3Gen model (consumer) converts them into audio. This decoupling prevents stalls and ensures a smooth, continuous flow of audio data.

Proactive Inference: The pipeline uses a signaling mechanism that allows the T3 model to proactively start processing the next chunk of text while the S3Gen model is still working on the current one. This advanced optimization minimizes gaps in audio generation, leading to a significant reduction in perceived latency for longer texts.

Real-Time TTS Generation Sequence

The real-time audio streaming is achieved through a multi-stage, asynchronous pipeline that ensures low latency and a non-blocking data flow from the initial request to the final audio stream.

sequenceDiagram
    participant Client
    participant Master as FastAPI Master
    participant ZMQ_Jobs as Job Queue (ZMQ)
    participant Worker
    participant T3_Producer as T3 Producer Task
    participant S3Gen_Producer as S3Gen Producer Task
    participant PCM_Consumer as PCM Consumer Task
    participant ZMQ_Results as Result Queue (ZMQ)

    Client->>+Master: POST /tts/generate
    Master->>ZMQ_Jobs: Push TTSRequest

    activate Worker
    ZMQ_Jobs->>Worker: Pull TTSRequest

    par
        Worker->>T3_Producer: Run(_t3_producer_task)
        activate T3_Producer
        T3_Producer-->>T3_Producer: Text -> Speech Tokens
        T3_Producer->>S3Gen_Producer: Enqueue Speech Tokens
        deactivate T3_Producer
    and
        Worker->>S3Gen_Producer: Run(_s3gen_producer_task)
        activate S3Gen_Producer
        S3Gen_Producer-->>S3Gen_Producer: Tokens -> GPU Audio
        S3Gen_Producer->>PCM_Consumer: Enqueue GPU Audio
        deactivate S3Gen_Producer
    and
        Worker->>PCM_Consumer: Run(_pcm_consumer_task)
        activate PCM_Consumer
        PCM_Consumer-->>PCM_Consumer: GPU Audio -> PCM Bytes
        PCM_Consumer->>Worker: Enqueue PCM Chunks
        deactivate PCM_Consumer
    end

    loop Audio Streaming
        Worker->>ZMQ_Results: Push Audio Chunk
        ZMQ_Results-->>Master: Pull Audio Chunk
        Master-->>Client: Stream Audio Chunk
    end

    deactivate Worker
    deactivate Master

Voice Management API

The service provides a set of RESTful endpoints to manage custom voices.

Voice Caching and Management

The voice management system is designed for efficiency and scalability. When a voice is uploaded, it is stored persistently. To ensure the lowest possible latency, the application automatically pre-caches all available voices into memory on startup. This means that all voices are ready for immediate use without any warm-up delay on the first request. The cache is also intelligently invalidated and updated whenever a voice is uploaded or deleted.

Upload a Voice

Endpoint: POST /voices

Description: Upload a new voice file. The voice_id will be the filename.

Request: multipart/form-data with a file named voice.wav.

Headers: X-API-Key: <YOUR_API_KEY>

Example with curl:

curl -X POST \
  -H "X-API-Key: <YOUR_API_KEY>" \
  -F "file=@/path/to/your/voice.wav" \
  http://localhost:8000/voices

Success Response (201 Created):

{
  "voice_id": "voice.wav",
  "message": "Voice uploaded successfully."
}

List Voices

Endpoint: GET /voices

Description: Get a list of all available voice IDs.

Headers: X-API-Key: <YOUR_API_KEY>

Example with curl:

curl -X GET \
  -H "X-API-Key: <YOUR_API_KEY>" \
  http://localhost:8000/voices

Success Response (200 OK):

["voice1.wav", "voice2.mp3"]

Delete a Voice

Endpoint: DELETE /voices/{voice_id}

Description: Delete a specific voice by its ID.

Headers: X-API-Key: <YOUR_API_KEY>

Example with curl:

curl -X DELETE \
  -H "X-API-Key: <YOUR_API_KEY>" \
  http://localhost:8000/voices/voice.wav

Success Response (200 OK):

{
  "message": "Voice 'voice.wav' deleted successfully."
}

RunPod Deployment Notes

This project is optimized for deployment on cloud platforms like RunPod, where you can easily deploy the container as a serverless GPU endpoint. When deploying on RunPod, ensure you:

Use the Docker image you built (your-docker-username/chatterbox-tts:latest) or the pre-built image from Docker Hub (akashdeep000/chatterbox-tts:latest).

Configure a persistent volume and map it to /app/voices in the container.

Expose the container's port 8000.

This setup allows you to manage a scalable, high-performance TTS service with ease.

Like this project

Completed work

Posted Aug 26, 2025

Developed a scalable TTS service with real-time audio streaming.

Likes

Views

Chatterbox TTS: Real-Time Text-to-Speech Service

Akashdeep via Replit

Completed work

Backend Engineer

AI Developer

Docker

FastAPI

Electronics

Chatterbox TTS

Project Overview

High-Level Architecture

Job Queue (PUSH/PULL): The master pushes TTS requests to a central queue, and idle workers pull jobs from it.

Result Channel (PUSH/PULL): Workers push the resulting audio chunks back to the master, which then streams them to the client.

Broadcast Channel (PUB/SUB): The master sends control commands (e.g., to warm up a new voice's cache or cancel a request) to all workers simultaneously.

This architecture allows the API to remain highly responsive while the workers independently handle the heavy lifting of audio generation.

graph TD
    subgraph "Client"
        A[User Application / Web UI]
    end

    subgraph "Master Process (FastAPI)"
        API[FastAPI App]
        VM[Voice Manager]
        ZMQ_Master[ZeroMQ Sockets]
        API -- Manages --> VM
        API -- Uses --> ZMQ_Master
    end

    subgraph "Inter-Process Communication (ZeroMQ)"
        JobQ[(Job Queue PUSH/PULL)]
        ResultQ[(Result Queue PUSH/PULL)]
        BroadcastQ[(Broadcast PUB/SUB)]
    end

    subgraph "Worker Processes"
        subgraph "Worker 0"
            W0[TTS Engine]
        end
        subgraph "Worker 1"
            W1[TTS Engine]
        end
        subgraph "Worker N"
            WN[TTS Engine]
        end
    end

    subgraph "Hardware Resources"
        G0[GPU 0]
        G1[GPU 1]
        GN[GPU N]
        H[Persistent Volume for Voices]
    end

    A -- "HTTP Request" --> API
    API -- "Dispatches Job" --> JobQ
    JobQ -- "Pulls Job" --> W0 & W1 & WN

    W0 & W1 & WN -- "Pushes Result" --> ResultQ
    ResultQ -- "Streams to Client" --> API

    API -- "Broadcasts Command" --> BroadcastQ
    BroadcastQ -- "Subscribes" --> W0 & W1 & WN

    W0 -- "Runs on" --> G0
    W1 -- "Runs on" --> G1
    WN -- "Runs on" --> GN
    VM -- "Load/Save Voices" --> H

    style G0 fill:#ccf,stroke:#333,stroke-width:2px
    style G1 fill:#ccf,stroke:#333,stroke-width:2px
    style GN fill:#ccf,stroke:#333,stroke-width:2px
    style H fill:#cfc,stroke:#333,stroke-width:2px
    style JobQ fill:#f9f,stroke:#333,stroke-width:2px
    style ResultQ fill:#f9f,stroke:#333,stroke-width:2px
    style BroadcastQ fill:#f9f,stroke:#333,stroke-width:2px

Prerequisites

To run this project, you will need:

Docker: The application is containerized and requires Docker to be installed.

GPU: A CUDA-enabled GPU is necessary for the TTS model to perform efficiently.

Configuration

Configuration is managed via environment variables. You can set them in your shell or create a .env file in the project root.

Core Application Settings

TTS Engine Tuning

These parameters control the TTS engine's behavior and can be set via environment variables prefixed with TTS_.

Example `.env` file

# Server Settings
API_KEY="your-super-secret-api-key"
CONCURRENT_REQUESTS_PER_WORKER=2 # Allow 2 TTS tasks per GPU

# TTS Tuning for Low Latency
TTS_SPEECH_TOKEN_QUEUE_MAX_SIZE=2
TTS_PCM_CHUNK_QUEUE_MAX_SIZE=3

Setup and Deployment

1. Build the Docker Image

From the project's root directory, build the Docker image:

docker build -t chatterbox-tts:latest .

2. Run the Docker Container

Run the container, mapping port 8000, providing the environment variables, and mounting a volume for persistent voice storage:

docker run -d -p 8000:8000 \
  --gpus all \
  -v $(pwd)/voices:/app/voices \
  -v $(pwd)/preloaded-voices:/app/preloaded-voices \
  --env-file .env \
  --name chatterbox-tts \
  chatterbox-tts:latest

Docker Hub and GitHub Actions

Using the Pre-built Docker Image

Instead of building the Docker image locally, you can use the pre-built image from Docker Hub, which is automatically updated with the latest changes.

Pull the Image

docker pull akashdeep000/chatterbox-tts:latest

Run the Container

Use the pulled image to run the container:

docker run -d -p 8000:8000 \
  --gpus all \
  -v $(pwd)/voices:/app/voices \
  -v $(pwd)/preloaded-voices:/app/preloaded-voices \
  --env-file .env \
  --name chatterbox-tts \
  akashdeep000/chatterbox-tts:latest

Note: If you are using a GPU, you may need to add --gpus all to the docker run command.

Automated Builds with GitHub Actions

This repository uses GitHub Actions to automate the building and publishing of the Docker image to Docker Hub. On every push, a new image is built and tagged with latest and the commit SHA.

You can view the workflow configuration at .github/workflows/publish-docker.yml.

Setup

To enable the workflow to publish to your Docker Hub account, you need to configure the following repository secrets and variables in your GitHub repository settings:

DOCKERHUB_USERNAME:

Type: Variable

Value: Your Docker Hub username.

Go to Settings > Secrets and variables > Actions > Variables and add a new repository variable.

DOCKERHUB_TOKEN:

Type: Secret

Value: Your Docker Hub access token. You can generate one in your Docker Hub account settings.

Go to Settings > Secrets and variables > Actions > Secrets and add a new repository secret.

API Usage

System Status: `GET /system-status`

Provides real-time CPU, RAM, and GPU utilization details. Useful for monitoring the health and load of the service.

Example with curl:

curl -X GET -H "X-API-Key: <YOUR_API_KEY>" http://localhost:8000/system-status

Example Response:

{
  "cpu": {
    "utilization_percent": 25.8,
    "ram_gb": {
      "total": 31.26,
      "used": 8.94,
      "free": 22.32,
      "percent_used": 28.6
    }
  },
  "gpus": [
    {
      "device_id": 0,
      "utilization_percent": { "gpu": 45, "memory": 28 },
      "memory_gb": { "total": 15.75, "used": 3.15, "free": 12.6 }
    },
    {
      "device_id": 1,
      "utilization_percent": { "gpu": 10, "memory": 15 },
      "memory_gb": { "total": 15.75, "used": 1.5, "free": 14.25 }
    }
  ]
}

TTS Generation: `/tts/generate`

This endpoint generates and streams audio in real-time. It supports both GET and POST requests, providing flexibility for different use cases.

Authentication

For all requests to this endpoint, the API key can be provided in one of two ways:

Header: X-API-Key: <YOUR_API_KEY>

Query Parameter: ?api_key=<YOUR_API_KEY>

POST Request

This method is suitable for server-to-server communication or when the text is long.

Example with curl:

curl -X POST \
  -H "Content-Type: application/json" \
  -H "X-API-Key: <YOUR_API_KEY>" \
  -d '{"text": "Hello, this is a custom voice.", "voice_id": "your_voice.wav"}' \
  http://localhost:8000/tts/generate --output custom_voice_output.wav

GET Request

This method is ideal for use in web browsers, as it allows you to set the endpoint URL directly as the src of an <audio> tag.

Example with curl:

curl -X GET "http://localhost:8000/tts/generate?text=Hello%20world&voice_id=your_voice.wav&api_key=<YOUR_API_KEY>&format=mp3" --output output.mp3

Example in HTML:

<audio
  controls
  src="http://localhost:8000/tts/generate?text=Hello%20world&api_key=<YOUR_API_KEY>&format=mp3"
></audio>

Advanced Usage: Streaming with Media Source Extensions (MSE)

The fmp4 (Fragmented MP4) format is recommended for use with MSE.

Example with MSE:

<!DOCTYPE html>
<html lang="en">
  <head>
    <meta charset="UTF-8" />
    <title>MSE Streaming Example</title>
  </head>
  <body>
    <h1>Real-time TTS Streaming with MSE</h1>
    <audio id="audioPlayer" controls></audio>
    <br />
    <input
      type="text"
      id="textInput"
      value="Hello from the world of real-time audio streaming."
    />
    <button id="playButton">Play</button>

    <script>
      const audioPlayer = document.getElementById("audioPlayer");
      const textInput = document.getElementById("textInput");
      const playButton = document.getElementById("playButton");
      const apiKey = "YOUR_API_KEY"; // Replace with your actual API key

      playButton.addEventListener("click", async () => {
        const text = encodeURIComponent(textInput.value);
        const url = `http://localhost:8000/tts/generate?text=${text}&api_key=${apiKey}&format=fmp4`;

        if (
          window.MediaSource &&
          MediaSource.isTypeSupported('audio/mp4; codecs="mp4a.40.2"')
        ) {
          const mediaSource = new MediaSource();
          audioPlayer.src = URL.createObjectURL(mediaSource);

          mediaSource.addEventListener("sourceopen", () => {
            const sourceBuffer = mediaSource.addSourceBuffer(
              'audio/mp4; codecs="mp4a.40.2"'
            );

            fetch(url)
              .then((response) => {
                if (!response.ok) {
                  throw new Error(`HTTP error! status: ${response.status}`);
                }
                const reader = response.body.getReader();

                function push() {
                  reader
                    .read()
                    .then(({ done, value }) => {
                      if (done) {
                        if (!mediaSource.ended) {
                          mediaSource.endOfStream();
                        }
                        return;
                      }
                      sourceBuffer.appendBuffer(value);
                      push();
                    })
                    .catch((err) => {
                      console.error("Error reading stream:", err);
                    });
                }

                sourceBuffer.addEventListener("updateend", push, {
                  once: true,
                });
                push();
              })
              .catch((e) => console.error("Fetch error:", e));
          });

          audioPlayer.play();
        } else {
          console.error("MSE or the required codec is not supported.");
          // Fallback for browsers that don't support MSE
          audioPlayer.src = url;
          audioPlayer.play();
        }
      });
    </script>
  </body>
</html>
