SMS Spam Detection Using Neural Networks

Quick Overview

Problem: Build a binary text classifier to distinguish between legitimate messages ("ham") and spam SMS using natural language processing and deep learning.

Solution: Implemented a neural network with text vectorization and word embeddings to classify SMS messages, achieving robust spam detection through sequential text processing.

Impact: Created a production-ready spam filter with high accuracy on unseen messages, demonstrating proficiency in NLP, text preprocessing, and TensorFlow text classification pipelines.

Step-by-Step Implementation

Step 1: Environment Setup & Library Installation

What: Installed a stable TensorFlow version and imported required libraries.

Key Libraries:

TensorFlow / Keras for neural networks

Pandas for data handling

TensorFlow Datasets for utilities

NumPy for numerical operations

Matplotlib for visualization

Version Control: Ensured a stable TensorFlow installation by removing tf-nightly if present.

Step 2: Data Acquisition

What: Downloaded the SMS Spam Collection dataset using wget.

Dataset Files:

train-data.tsv: Training messages

valid-data.tsv: Testing and validation messages

Format: Tab-separated values (TSV) with label and message columns.

Source: FreeCodeCamp project data repository.

Step 3: Data Loading & Exploration

What: Loaded TSV files into Pandas DataFrames.

Structure:

Column 1: Label (ham or spam)

Column 2: Message text content

Initial Analysis: Examined the first few rows to understand data format and distribution.

Key Finding: Dataset is imbalanced, with significantly more ham than spam messages.

Step 4: Label Encoding

Problem: The model requires numerical labels, but the dataset contains text labels.

Solution: Binary encoding of labels.

ham → 0 (legitimate message)

spam → 1 (spam message)

Implementation: Converted labels into NumPy arrays.

Result: Training and validation labels represented in binary format (0/1).

Step 5: Text Preprocessing Pipeline

Custom Standardization Function: Implemented a text cleaning pipeline.

Converted text to lowercase

Removed HTML tags such as <br /> using regular expressions

Removed punctuation and special characters

Purpose: Normalize text variations (for example, "FREE" versus "free") for consistent processing.

Impact: Reduced vocabulary size and improved model generalization.

Step 6: Text Vectorization Configuration

Layer: TextVectorization from Keras.

Parameters:

max_tokens = 10,000: Vocabulary size limit

sequence_length = 120: Fixed output length with padding and truncation

output_mode = 'int': Convert words to integer indices

standardize = custom_standardization: Apply text cleaning function

Vocabulary Building: Adapted the vectorization layer on training messages only.

Result: Learned a word-to-index mapping based on the training corpus.

Step 7: Message Vectorization

Process: Converted text messages into integer sequences.

Training data: train_messages → train_sequences

Test data: test_messages → test_sequences

Example Output:

Original: "Free money now!"

Vectorized: [42, 187, 933, 0, 0, ...] (padded to length 120)

Benefit: Enabled neural network processing of numerical sequences.

Step 8: Neural Network Architecture Design

Model Type: Sequential neural network for binary text classification.

Architecture:

Embedding layer: Converts word indices into 16-dimensional dense vectors

Dropout layer (20%) for regularization

GlobalAveragePooling1D layer to aggregate sequence information

Dropout layer (20%) before final output

Dense output layer with 1 neuron and sigmoid activation

Why This Architecture:

Embeddings learn semantic word representations

Global average pooling handles variable-length sequences

Dropout reduces overfitting

Sigmoid outputs probabilities between 0 (ham) and 1 (spam)

Step 9: Model Compilation

Optimizer: Adam, suitable for NLP tasks due to adaptive learning rates.

Loss Function: Binary crossentropy, standard for binary classification.

Metric: Accuracy as the primary evaluation metric.

Configuration: Optimized for binary text classification.

Step 10: Dataset Analysis

Class Distribution Check:

Counted ham versus spam messages in the training set

Calculated spam ratio percentage

Purpose: Identify class imbalance, which affects evaluation and interpretation.

Finding: Dataset contains more ham messages than spam.

Implication: Accuracy must be interpreted carefully due to imbalance.

Step 11: Model Training

Training Configuration:

Epochs: 60

Validation data: Vectorized test sequences

Verbose: 1 (progress bars enabled)

Data Used: Vectorized message sequences and binary labels.

Monitoring: Tracked accuracy and loss on both training and validation sets.

Result: Model learned patterns distinguishing spam from legitimate messages.

Step 12: Post-Training Verification

Immediate Testing: Generated predictions for a sample spam message.

Example:

"you have won £1000 cash! call to claim your prize."

Vocabulary Check: Verified that 10,000 words were learned.

Sanity Check: Confirmed output probabilities aligned with expectations.

Purpose: Ensure the model learned meaningful spam indicators such as "won," "prize," and "cash."

Step 13: Model Evaluation

Test Set Performance: Evaluated on unseen validation data.

Metrics Reported:

Test accuracy

Test loss (binary crossentropy)

Purpose: Measure generalization to new messages.

Result: High accuracy indicating effective spam detection.

Step 14: Model Persistence

What: Saved the trained model to disk.

Format: Keras native format (.keras).

Filename: spam_model.keras

Benefit: Enables model reuse without retraining.

Use Case: Deployment or continued development.

Step 15: Prediction Function Implementation

Function: predict_message(pred_text)

Input: Single message string.

Process:

Vectorize input text using the trained vectorize_layer

Generate a probability prediction between 0 and 1

Apply threshold: ≥ 0.5 → spam, < 0.5 → ham

Output Format: [probability_float, label_string]

Example: [0.9234, 'spam'] or [0.1567, 'ham']

Key Design: Returns both probability and label for interpretability.

Step 16: Comprehensive Testing

Test Suite: Seven diverse messages covering edge cases.

Examples Include:

Normal conversation

Obvious spam

Scheduling messages

Service notifications

Prize scams

Casual reminders

Personal stories

Validation: Compared predictions against expected labels.

Output: Detailed report with probability, prediction, and correctness.

Result:

✅ Successfully classified all test cases.

Step 17: Final Validation

Automated Test: Built-in test_predictions() function.

Pass Criteria: All seven test messages correctly classified.

Result:

✅ "You passed the challenge. Great job!"

Verification: Model generalizes effectively across varied message types.
