Healthcare Cost Prediction Using Neural Networks by Nathanael MbaleHealthcare Cost Prediction Using Neural Networks by Nathanael Mbale

Healthcare Cost Prediction Using Neural Networks

Nathanael Mbale

Completed work

Data Scientist

AI Developer

AI Engineer

Matplotlib

pandas

TensorFlow

Healthcare

Healthcare Cost Prediction Using Neural Networks

Quick Overview

Problem: Predict individual healthcare costs using regression analysis on demographic and health data, achieving Mean Absolute Error (MAE) under $3,500.

Solution: Built a deep neural network regression model with feature normalization and categorical encoding to predict medical expenses from patient characteristics.

Impact: Achieved $2,800 MAE (20% better than the requirement), demonstrating proficiency in regression modeling, data preprocessing, and TensorFlow/Keras implementation.

Completed Project

https://colab.research.google.com/drive/1TzGEH3w3DyVbxumFz2LufzQEgTDMPYgX?usp=drive_link

Step-by-Step Implementation

Step 1: Environment Setup & Data Loading

What: Imported TensorFlow 2.x, Keras, and a healthcare insurance dataset.

Dataset: insurance.csv containing patient information and medical costs.

Key Libraries:

TensorFlow / Keras for neural networks

Pandas for data manipulation

Matplotlib for visualization

tensorflow_docs for training callbacks

Step 2: Data Exploration

What: Examined dataset structure and features.

Features Identified:

Numerical: age, bmi, children

Categorical: sex, smoker, region

Target Variable: expenses (healthcare costs)

Initial Analysis: Used dataset.tail() to inspect data structure and identify preprocessing needs.

Step 3: Categorical Data Encoding

Problem: Neural networks require numerical inputs, but the dataset contains text categories.

Solution: Manual mapping of categorical variables to numerical values.

Sex: male → 0, female → 1

Smoker: no → 0, yes → 1

Region:

southwest → 0

southeast → 1

northwest → 2

northeast → 3

Key Action: Applied string stripping to handle whitespace before mapping.

Impact: Converted all features to numerical format for model compatibility.

Step 4: Train-Test Split

Split Ratio: 80% training, 20% testing.

Method: Random sampling using frac=0.2 for the test set.

Implementation:

Test dataset: 20% random sample from original data

Train dataset: Remaining 80%, created by dropping test indices

Label Separation:

Popped the expenses column to create labels

train_labels: target values for training

test_labels: target values for evaluation

Step 5: Feature Normalization

Problem: Features exist on different scales (age: 18–64, BMI: 15–50, expenses: $1k–$60k), causing training instability.

Solution: Z-score normalization (standardization).

Calculated mean and standard deviation from training data only

Applied formula: (x − mean) / std

Critical Decision: Used training statistics for both training and test data to prevent data leakage.

Impact:

Faster convergence during training

Improved gradient descent stability

Better model generalization

Step 6: Neural Network Architecture Design

Model Type: Sequential feedforward neural network for regression.

Architecture:

Input layer: 6 features after encoding

Hidden Layer 1: 64 neurons, ReLU activation

Hidden Layer 2: 64 neurons, ReLU activation

Output Layer: 1 neuron for continuous cost prediction

Rationale:

Two hidden layers capture non-linear relationships

ReLU activation avoids vanishing gradients

64 neurons balance learning capacity and overfitting risk

Step 7: Model Compilation

Optimizer: RMSprop (learning rate = 0.001)

Adaptive learning rate suitable for regression

Handles sparse gradients effectively

Loss Function: Mean Squared Error (MSE)

Standard loss for regression

Penalizes large errors more heavily

Metrics Tracked:

MAE (Mean Absolute Error): primary evaluation metric

MSE (Mean Squared Error): secondary monitoring metric

Step 8: Model Training

Training Configuration:

Epochs: 500

Validation split: 20% of training data

Verbose: 0 with EpochDots callback

Data Used: Normalized training data

Monitoring: Validation loss tracked to detect overfitting.

Result: Model learned relationships between patient features and healthcare costs.

Step 9: Model Evaluation

Test Evaluation: model.evaluate() on normalized test data.

Key Metric: Mean Absolute Error (MAE)

Performance Achieved: $2,800 MAE

Target: ≤ $3,500

✅ Beat target by $700 (20% improvement).

Interpretation: Model predictions are, on average, $2,800 away from actual healthcare costs.

Step 10: Prediction Visualization

What: Generated a scatter plot of true versus predicted expenses.

Plot Elements:

X-axis: Actual healthcare costs (test_labels)

Y-axis: Model predictions

Diagonal line: Perfect prediction reference

Equal aspect ratio for accurate comparison

Interpretation:

Points close to the diagonal indicate accurate predictions

Scatter distribution highlights model strengths and weaknesses

Visual confirmation of $2,800 MAE performance

Step 11: Final Validation

Automated Test: Built-in evaluation verifying MAE ≤ $3,500.

Result:

✅ "You passed the challenge. Great job!"

Verification: Model successfully generalizes to unseen test data.

Like this project

Completed work

Posted Dec 27, 2025

Built a neural network to predict healthcare costs with 20% better accuracy than the target.
