Redesigned Aqua Guard® called Aqua Guard® Ultraclean™

Vinay Dabhade

Vinay Dabhade

Objectives:

•Redesign of Brush designing to clean screen which is collect on elements.
• Installing two Spray wash header for more cleaning.
• Adding extra drive for belt assembly for more efficient cleaning.
• Redesigning the complete frame assembly for installing new components.
• This save onsite assembly, welding and installation cost, time and get better control in quality.

Key Responsibility:

• Create concepts & 3D model for newly design Aqua Guard® UltraClean™.
• Check constrains/ feasibility of modification.
• Send the final models to product manager with required constrains for final approval.
• Design the guide rail for proper guiding chain assembly and following energy efficient path.
• Added new sprays wash assembly for better performance & reduce maintenance cycle with detailed manufacturing drawings.
Like this project

Posted May 21, 2024

Create concepts & 3D model for newly design Aqua Guard® UltraClean™, which shows a capture rate improvement of over 50%.
