A compliance-focused RAG application for auditing privacy policy PDFs against regulatory frameworks such as GDPR, CCPA, HIPAA, and NIST.

The project combines Spark-based PDF ingestion, Azure AI Search retrieval, a Neo4j regulatory-framework knowledge graph, an Azure OpenAI-compatible LLM, a LangGraph compliance workflow, and a React frontend.

This is an assistive compliance review tool. It can surface possible gaps and remediation steps, but it does not replace legal review.

Demo video: Privacy-Compliance-Intelligence-Platform Demo Walkthrough.mp4

Important: privacy policies are not stored as policy nodes in Neo4j. Neo4j is used for the regulatory-framework knowledge graph.

Active LangGraph nodes:

This section maps the audit behavior to the actual files and functions in the project.

Step Implementation What happens in code PDF ingestion pipeline/spark_ingestion.py -> run_ingestion() Scans the input folder, distributes PDFs across Spark partitions, extracts text, chunks it, embeds it, and uploads documents to the selected Azure AI Search index. Text extraction pipeline/spark_ingestion.py -> extract_text() Uses PyMuPDF / pymupdf4llm for text PDFs. If is_scanned() finds very little embedded text, it falls back to Azure Document Intelligence OCR. Chunking pipeline/spark_ingestion.py -> chunk_text() Uses token chunking by default; semantic chunking is available through SemanticChunker. Each chunk keeps metadata such as paper_id, doc_type, regulation, page, and chunk_id. Framework KG build pipeline/kg_builder.py -> ComplianceKGBuilder.build_from_pdfs() Reads framework PDFs from data/regulations, splits them into article/section chunks, runs LLMGraphTransformer, and writes graph documents to Neo4j. KG node/edge schema pipeline/kg_builder.py -> ALLOWED_NODES, ALLOWED_RELATIONSHIPS Nodes include Regulation, Article, Obligation, Right, Entity, Concept, Penalty, and Timeframe. Edges include REQUIRES, GRANTS, REFERENCES, MAPS_TO, PART_OF, DEFINES, APPLIES_TO, IMPOSES, CONFLICTS_WITH, and STRICTER_THAN. Value conflict extraction pipeline/kg_builder.py -> _extract_value_conflicts() Runs a dedicated LLM pass over framework text and writes concrete CONFLICTS_WITH / STRICTER_THAN edges using Cypher. Stored properties include concept, value_a, value_b, unit, description, and source_quote. Policy selection agent/compliance_nodes.py -> doc_resolver_node() Uses the frontend dropdown value first. If absent, it tries filename/query matching; if multiple policies are possible, it returns a clarification response. Framework detection agent/compliance_nodes.py -> jurisdiction_detector_node() Detects the applicable regulatory frameworks from the question and available context. These names are then used to scope obligations, conflicts, and scoring. Evidence retrieval agent/compliance_nodes.py -> kg_retriever_node() and pipeline/compliance_retriever.py -> _azure_search() Retrieves policy chunks from Azure AI Search with a filter like doc_type eq 'policy' and paper_id eq '<selected.pdf>'. It also retrieves framework chunks from the framework index. KG context retrieval pipeline/compliance_retriever.py -> multi_hop() Extracts important terms from the retrieved text, then asks Neo4j for nearby connected framework facts. In plain English: if the query mentions breach notification, the graph helps pull related duties, timeframes, rights, penalties, and framework sections connected to that concept. Obligation structuring agent/compliance_nodes.py -> _triples_to_obligations() Converts Neo4j relationship results into simple obligation records with framework, obligation type, source, and text fields. Keyword rules classify obligations such as breach notification, data subject rights, access control, encryption, retention, consent, and lawful basis. Gap analysis agent/compliance_nodes.py -> gap_analyzer_node() and _analyze_gaps_with_llm() Sends the selected policy text plus structured obligations to the LLM in batches. The LLM returns JSON gaps with severity, framework, obligation ID, theme, evidence, and missing/weak policy language. Conflict filtering agent/compliance_nodes.py -> conflict_detector_node() Reads CONFLICTS_WITH and STRICTER_THAN edges from Neo4j and keeps only conflicts relevant to the detected frameworks for that audit. Priority scoring agent/compliance_nodes.py -> risk_scorer_node() Converts gaps into a simple prioritization score for the UI/report. Severity weights are critical=10, high=7.5, medium=5, low=2.5, info=1. Framework weights are GDPR=0.35, HIPAA=0.30, CCPA=0.20, NIST=0.15. The displayed compliance score is calculated by risk_to_compliance() = 100 - risk * 10, clamped to 0-100. This is not a legal certification score; it is a way to rank and summarize findings. Remediation agent/compliance_nodes.py -> remediation_node() and _generate_remediations() Groups gaps by closed-vocabulary themes and asks the LLM for one concrete checklist action per theme. The final report renders these as remediation checklist items. Runtime telemetry app/core/telemetry.py and agent/compliance_nodes.py Emits visible console logs and Application Insights traces for query_received, node_jurisdiction_detector, node_gap_analyzer, node_risk_scorer, and query_completed.

The important implementation detail is that the app does not simply ask an LLM to judge a policy from scratch. It first retrieves policy evidence from Azure AI Search, uses Neo4j to pull connected framework facts around the audit topic, converts those graph results into structured obligations, and then asks the LLM to compare the policy language against those obligations.

KG conflicts are value-level framework differences, for example different deadlines, thresholds, or limits for the same obligation. The conflict extraction focuses on breach notification deadlines, deletion/erasure response deadlines, data subject access deadlines, minor consent age thresholds, retention limits, and opt-out response deadlines.

Run these before using the app for audits.

This reads framework PDFs, extracts framework concepts/obligations with the LLM graph transformer, and writes the framework graph to Neo4j.

The same pipeline/spark_ingestion.py file handles extraction, scanned-PDF OCR fallback, chunking, embeddings, and Azure AI Search upload.

Policies can also be uploaded from the frontend Audit page through the embedded ingest component.

Create a root .env file:

Run the backend:

Create frontend/.env:

If using ngrok/Colab, set VITE_API_URL to the public backend URL and restart npm run dev.

Page Purpose Dashboard Backend status and sample audit questions. Audit Main audit UI, policy dropdown, streaming progress, gaps, remediation. History Recent audit runs and browser-downloaded history report.

Endpoint Purpose GET /api/v1/health Liveness check. GET /api/v1/health/ready Readiness check. POST /api/v1/query Run an audit query. POST /api/v1/query/stream Run an audit with streaming progress. POST /api/v1/ingest Upload policy PDFs. GET /api/v1/policies List indexed policy documents. GET /api/v1/history Read MLflow-backed audit history when configured. GET /api/v1/conflicts Read framework conflicts from Neo4j. GET /api/v1/regulations List indexed regulatory frameworks. GET /api/v1/regulations/chunks Browse regulatory-framework chunks.

The backend logs successful audit runs through mlops/compliance_tracker.py.

Logged items include:

Type Examples Parameters query, selected policy, jurisdictions Metrics compliance score, risk score, gap counts, latency Artifacts report markdown, gaps JSON, risk scores JSON

For Azure MLflow, set:

Then restart the backend and run an audit. The experiment name is:

Application Insights is used for runtime monitoring, not experiment artifacts.

Set:

Then restart the backend and run an audit. In Application Insights, check Logs or Transaction Search for events such as:

This system provides compliance assistance, not legal advice.

Policy filename changes do not anonymize company names inside PDF text.

If multiple policies exist and no policy is selected, the system may ask for clarification.

MLflow and Application Insights are optional observability layers.
