Secure Connect is a Node.js/Express middleware API that automates physical access control by integrating with the Gallagher security and monitoring platform. It exposes simplified, versioned, JWT-protected REST endpoints for managing cardholders — onboarding, credential (Access/MSIC card) issuance, access-group assignment, updates, and offboarding — instead of provisioning each one by hand in Gallagher's admin console.

The integration itself is built behind a Service + Adapter pattern, so Gallagher is treated as one pluggable backend rather than a hardcoded dependency — additional access-control vendors could be added without touching the core cardholder logic.

Manually provisioning physical access (creating a cardholder, issuing a card, assigning them to the correct access group, later revoking a lost card) in a vendor console doesn't scale and isn't auditable. Secure Connect turns that workflow into a small set of authenticated REST calls, with structured, PII-redacted logging for every request so actions are traceable after the fact.

JWT authentication — every cardholder/cache-management endpoint requires a valid Authorization: Bearer <token> issued by POST /api/v1/auth/login. Passwords are stored as bcrypt hashes; login attempts are rate-limited per IP to slow brute-force attempts. This is Secure Connect's own gate — Gallagher itself has no concept of JWT; it only ever sees the separate Gallagher API key described below.

Gallagher integration — mutual-TLS (client certificate, optional if Gallagher CC is configured to accept clients with none) plus API-key authentication to Gallagher's REST API, with an in-memory cache of resource hrefs (cardholders, divisions, access groups, operator groups) to minimize discovery calls.

Per-operator Gallagher attribution — create_cardholder/update_cardholder/delete_cardholder accept an optional X-Gallagher-Api-Key header. When present, that request's Gallagher-side action is attributed to that specific Gallagher REST Client identity instead of the shared server-configured key — useful when multiple operators use the same Secure Connect deployment but should show up distinctly in Gallagher's own audit trail. Falls back to the server's GALLAGHER_API_KEY when omitted. This is a separate, independent credential from the JWT bearer token — do not confuse the two headers.

Service + Adapter architecture — business logic (services/CardholderService.js) is decoupled from the vendor-specific client (api/gallagher/GallagherAdapter.js), so new integrations can be added by implementing the same adapter interface.

Request validation — Zod schemas validate every incoming payload (card types, card-number format, ISO date ordering, required fields) and return structured 400 errors.

Structured, audit-ready logging — Winston with daily-rotating file transports, correlation IDs propagated across a request's lifecycle, and automatic redaction/masking of names, emails, and card numbers in logs.

API versioning — all routes are namespaced under /api/v1 to allow non-breaking evolution.

Dockerized — ships with a Dockerfile for containerized deployment.

API console — a React + Material UI + Vite front end (with a Monaco JSON editor) for exercising every endpoint, including the login flow.

Loading

Loading

Loading

The Adapter Pattern makes it straightforward to add another vendor alongside Gallagher:

Create a new adapter in api/<vendorName>/<VendorName>Adapter.js, implementing the same public methods as GallagherAdapter.js (createCardholder, updateCardholder, deleteCardholder, findCardholderHrefByFirstName, findDivisionHrefByName, findCardNumberHref).

Implement the adapter's HTTP/auth logic for that vendor's API.

Wire it into the routes in routes/v1/cardholderRoutes.js, selecting an adapter based on a header, query parameter, or body field.

POST /api/v1/auth/login — public, rate-limited (5 attempts / 15 min / IP)

Body:

Response:

All routes below require Authorization: Bearer <token> from this response.

Validation rules are unified across create/update/delete via validatePersonBody in routes/v1/cardholderRoutes.js. The request body must be an object with a top-level person key.

Required: firstName (non-empty), cards (array, min 1)

Optional: lastName, email (valid email), divisionName, employmentCategory, photo (base64 JPEG, raw or data URI)

cardType: "Access" or "MSIC"

cardNumber: ^[A-Z0-9]{6,9}$ (case-insensitive input, normalized to uppercase), unique per request

activationDate / expiryDate: ISO 8601 datetime, expiryDate strictly after activationDate

type (optional) updates the Access card's status via a JSON Patch–style update to Gallagher.

The cardholder is located by person.firstName.

Locates the cardholder by firstName and deletes the first match — if multiple cardholders share a first name, disambiguate upstream in Gallagher before deleting.

GET /api/v1/cache_status — cache initialization state and cached hrefs. Self-warms the cache on a fresh process if it isn't initialized yet, so it doesn't just report an empty cache.

POST /api/v1/clear_cache — clears the in-memory href cache

GET /api/v1/cached_hrefs — returns cached Gallagher endpoint hrefs (also self-warms)

The href cache is in-memory per process — it resets on every restart, which is expected; the routes above re-populate it automatically on next use.

Validation failures (caught before any Gallagher call) return 400:

Errors from Gallagher itself (e.g. an invalid division, card type, or duplicate card number) also return the upstream status code, with Gallagher's own message surfaced directly rather than a generic axios error:

Missing/invalid/expired tokens return 401. Exceeding the login rate limit returns 429. Unhandled server errors return 500.

update_cardholder currently requires a non-empty cards array in every request, even if you only want to change lastName/description/etc. and aren't touching cards. This is a validation gap (the schema is shared with create_cardholder), not a Gallagher limitation.

delete_cardholder matches by firstName only and deletes the first result — if more than one cardholder shares a first name, disambiguate in Gallagher first.

There's no way to change an existing card's type (Access ↔ MSIC) — Gallagher models that as issuing a new card, not editing one. update_cardholder's type field only changes an Access card's status (e.g. Lost/Active).

Gallagher credentials (API key + client certificate passphrase) live only in config/secrets.env, which is gitignored — they are never sent from the browser.

All names, emails, and card numbers are redacted or masked before being written to logs (utils/logger.js).

The bundled login is a single configured account intended for a demo/portfolio deployment; swap AUTH_USERNAME/AUTH_PASSWORD_HASH for a real user store before using this in production with multiple operators.

Contributions and suggestions are welcome — open an issue or a pull request.
