MAVMRF
Maritime Autonomous Vehicle Monitoring and Response Framework — a simulation-first Python pipeline for multi-sensor maritime detect, track, and classify.
Built by Fratres X AI — reviewable AI, autonomy, and defensive-technology prototypes with physics-first modeling and conservative maturity labels.
On a fresh clone, monitor mode uses simulation detections by default (no YOLO download). YOLO is opt-in via training,
--pretrained, or --weights. There is no hosted web demo — clone it, run it, fork it.Layout note: Application code lives in themarmf/directory; the installable package name ismavmrf.
Still frame:
Contents
Highlights
Multi-sensor simulation — sonar, acoustic, optical, and magnetic streams
Honest detection modes — simulation default; YOLO when trained or explicitly requested
Fusion & tracking — IoU-matched object IDs, weighted fusion, SORT-style tracks
Operator outputs — bearing, estimated range, bearing rate, contact typing, change detection
File replay — JSON frames via
JsonFileSensorAdapter (incoming_data/samples/)Reproducible gates — seeded benchmark under
docs/benchmarks/Automated tests + GitHub Actions CI
Local demo (this is the live path)
No cloud app. The demo is a local run that writes reports and visualizations under
marmf/reports/.This is the Fratres X open-source posture: you run the stack.
Equivalent one-liner after install:
Regenerate the README GIF from a short run:
Quick start
From the repo root:
Reports include
detection_source (simulation, trained, pretrained, or explicit).Detection modes
Mode How to enable
simulation (default) No flags; uses simulator optical detections trained After main.py --mode train; auto-loads best.pt pretrained --pretrained (downloads yolov8n.pt) explicit --weights PATHUse
--no-trained to skip auto-loading local trained weights.Optional: train on synthetic data
Architecture
See
docs/ARCHITECTURE.md for pipeline diagram, module map, extension points, and how MAVMRF sits next to other Fratres X defensive-sensing / contested-autonomy work.Design decisions and tradeoffs
Maturity: simulation / prototype — not a fielded maritime C2 product.
Choice Why Tradeoff Simulation detections by default Fresh clone stays honest and offline; no silent COCO YOLO download Optical “detections” are synthetic until you train or pass
--weights / --pretrained IoU match before fusion Keeps sonar/acoustic/magnetic joins on the same contact when YOLO boxes differ from sim boxes Assumes overlapping 2D boxes; not a full 3D association layer SORT-style tracker Fast, reviewable track continuity for demos and gates No deep appearance re-ID; coasting behavior is deliberately simple Weighted multi-sensor fusion Makes the multi-modal story concrete in reports Weights are heuristic, not learned calibration from real sensors Clone-and-run only Matches Fratres X “you run it, you own the stack” open-source posture No hosted demo for drive-by clicksThis thread sits alongside Fratres X work on defensive sensing and contested autonomy: multi-modal streams, conservative fusion, and outputs you can audit — without claiming operational readiness.
What we would change next
Real adapter implementations behind
SensorAdapter (AIS / acoustic / optical feeds) with recorded replay fixturesAssociation beyond 2D IoU (bearing-range gates, timing uncertainty)
Calibration / clutter models grounded in measured sensor noise, not only sim knobs
Stronger track lifecycle metrics (continuity, ID switches) in the seeded benchmark
Optional Docker one-liner for locked environments — still local, still yours
Seeded benchmark
Fixed-seed simulation gate (not field performance):
Results live in
docs/benchmarks/ (README.md + seeded_run.json).Related work
MAVMRF is a simulation-first lab baseline. Domain surveys and open trackers that situate the design:
Survey: Multi-sensor data fusion in maritime surveillance (PeerJ) — fusion methods; YOLO + tracking as common optical paths.
Benchmark: Autoferry sensor fusion dataset — multi-sensor MOT fixtures with ground truth.
Validated tracker: harbour-multi-sensor-tracking — radar/camera/AIS/GNSS + EKF/Hungarian, sim + harbour runs.
Full comparison table:
docs/RELATED_WORK.md.Related Fratres X threads
Sibling lab threads on fratres-x.com — same posture: physics-first modeling, conservative maturity labels, reviewable prototypes.
Thread Focus Charybdis Contested autonomy — hybrid UUV navigation, conservative fusion, validation gates Anti Edge Node Defensive sensing — acoustic / RF / visual fusion, audit logs, field-node concept HYPERLINK Missile-defense modeling — imperfect model constellations, uncertainty, simulation
Profile pin checklist:
docs/PROFILE_SETUP.md.Documentation
Doc Description docs/README.md Documentation index docs/ARCHITECTURE.md Pipeline and extension points docs/RELATED_WORK.md Surveys, benchmarks, how MAVMRF fits docs/benchmarks/ Seeded reproducible gates docs/ZENODO_SETUP.md Mint a Zenodo DOI for releases docs/SOLUTION_BRIEF.md Executive narrative docs/capability_matrix.md Capability → evidence docs/DEMO_SCRIPT_3_MIN.md Demo script CHANGELOG.md Release history SUPPORT.md Where to get help SECURITY.md Vulnerability reporting
Full CLI reference:
marmf/README.md.Repository layout
Path Description
marmf/ Core framework (package name mavmrf) docs/ Architecture, brief, samples, screenshots, benchmarks CONTRIBUTING.md Setup, tests, CI marmf/tests/ Pytest suiteTech stack
Python 3.12 · OpenCV · NumPy · Ultralytics (YOLOv8) · PyTorch · Matplotlib · SciPy · pytest · ruff
Contributing
See CONTRIBUTING.md. By participating, you agree to the Code of Conduct.
Citation
See CITATION.cff. Prefer the “Cite this repository” button on GitHub when available.
Disclaimer
Portfolio prototype using simulated sensor data. Not intended for operational deployment without live sensor integration and validation. Built for scrutiny — not for inflated claims.
License
MIT — see LICENSE.
