Hybrid Optimization Algorithm for Tunable RF/Microwave Filters

High-performance tunable radio frequency (RF)/ microwave and millimeter-wave filter design is a challenging task due to the lack of a basic theory. The filtering characteristics are highly sensitive to the variation of tuning elements that are commonly modeled and achieved by optimization algorithms. However, those optimizations only provide satisfactory results with a good set of initial parameters. Such range-limited optimization algorithms generally have issues of falling into local optima, slow convergence, and cumbersome implementation. To mitigate this problem, for the first time, a topology-based local optimizer is integrated with metaheuristic global optimization algorithms in this work. We have hybridized the homotopy method with an improved whale optimization algorithm (WOA) and a gray wolf optimization (GWO) algorithm. In this work, an artificial neural network (ANN) is formulated and studied, which has twofold applications. First, ANN is used as a surrogate model to represent the time-consuming electromagnetic (EM) model in expediting the hybrid optimization process of tunable filters. Second, an ANN model is developed on data generated by the proposed optimization algorithm for predicting tunable circuit parameters at different tuning stages. The proposed ANN model-based algorithm is then applied to a fifth-order lumped-element tunable circuit and two fourth-order full-wave EM simulation models of two tunable bandpass filters (tBPFs). The calculated results out of the ANN model demonstrate a good agreement with simulation and measurement counterparts.

Published in: IEEE Transactions on Microwave Theory and Techniques ( Volume: 71, Issue: 6, June 2023)

Page(s): 2567 - 2581
