Todo Microservices Application

A production-ready, full-stack todo application built with microservices architecture using Node.js, TypeScript, React, and MySQL. Features complete Docker containerization and comprehensive test coverage.

📋 Table of Contents

Architecture Overview

Running the Application

Docker Deployment

Testing

API Documentation

Environment Variables

Troubleshooting

🏗 Architecture Overview

This application follows a microservices architecture with complete containerization support:

┌─────────────────────────────────────────────┐
│                   Nginx                      │
│              (Reverse Proxy)                 │
│                 Port: 80                     │
└────────────────────┬─────────────────────────┘
                     │
         ┌───────────┼───────────┐
         │           │           │
    ┌────▼────┐ ┌────▼────┐ ┌───▼────┐
    │Frontend │ │  User   │ │  Todo  │
    │ (React) │ │ Service │ │Service │
    │   :80   │ │  :3001  │ │ :3002  │
    └─────────┘ └────┬────┘ └───┬────┘
                     │           │
                ┌────▼────┐ ┌────▼────┐
                │  MySQL  │ │  MySQL  │
                │ userdb  │ │ tododb  │
                └─────────┘ └─────────┘

Services:

User Service - Handles authentication (register/login) and JWT token generation

Todo Service - Manages CRUD operations for todos with JWT validation

Frontend - React application with Ant Design UI components

Nginx - Reverse proxy for routing and serving static files (Docker mode)

🛠 Tech Stack

Backend

Runtime: Node.js (v18+)

Language: TypeScript

Framework: Express.js

Database: MySQL 8.0

ORM: TypeORM

Authentication: JWT (jsonwebtoken)

Validation: Joi

Security: Helmet, CORS, bcrypt

Testing: Jest, Supertest (95% coverage)

Containerization: Docker, Docker Compose

Frontend

Framework: React 18

UI Library: Ant Design (antd)

Routing: React Router v6

HTTP Client: Axios

State Management: React Hooks

Styling: CSS, Ant Design styles

Build: Create React App

DevOps

Containerization: Docker, Docker Compose

Testing: Jest, Supertest

Code Quality: ESLint, Prettier

📦 Prerequisites

For Local Development:

Node.js (v16.0.0 or higher)

npm (v7.0.0 or higher)

MySQL (v8.0 or higher)

Git

For Docker Deployment:

Docker (v20.10.0 or higher)

Docker Compose (v2.0.0 or higher)

Verify Installation:

# Local development
node --version    # Should output v16.x.x or higher
npm --version     # Should output v7.x.x or higher
mysql --version   # Should output 8.x.x

# Docker deployment
docker --version
docker-compose --version

📁 Project Structure

todo-microservices/
├── user-service/
│   ├── src/
│   │   ├── config/         # Database and environment config
│   │   ├── controllers/    # Request handlers
│   │   ├── middlewares/    # Custom middleware
│   │   ├── models/         # Database models
│   │   ├── routes/         # API routes
│   │   ├── services/       # Business logic
│   │   ├── utils/          # Utility functions
│   │   ├── validators/     # Input validation schemas
│   │   ├── types/          # TypeScript types
│   │   ├── app.ts          # Express app setup
│   │   └── index.ts        # Entry point
│   ├── tests/
│   │   ├── unit/           # Unit tests
│   │   ├── integration/    # Integration tests
│   │   └── setup.ts        # Test configuration
│   ├── Dockerfile          # Docker configuration
│   ├── Dockerfile.dev      # Development Docker config
│   ├── package.json
│   ├── tsconfig.json
│   ├── jest.config.js
│   ├── .env
│   ├── .dockerignore
│   └── nodemon.json
│
├── todo-service/
│   ├── src/
│   │   └── [Similar structure as user-service]
│   ├── tests/
│   │   └── [Similar structure as user-service]
│   ├── Dockerfile
│   ├── Dockerfile.dev
│   └── [Similar config files]
│
├── frontend/
│   ├── public/
│   ├── src/
│   │   ├── components/     # Reusable components
│   │   ├── pages/          # Page components
│   │   ├── services/       # API services
│   │   ├── utils/          # Utility functions
│   │   ├── App.js          # Main App component
│   │   └── index.js        # Entry point
│   ├── Dockerfile
│   ├── nginx.conf          # Nginx configuration
│   ├── package.json
│   └── .env
│
├── docker-compose.yml       # Production Docker orchestration
├── docker-compose.dev.yml   # Development Docker orchestration
├── Makefile                # Convenience commands
├── init-db/
│   └── init.sql            # Database initialization
└── README.md               # This file

🚀 Installation & Setup

Option 1: Quick Start with Docker (Recommended)

# Clone the repository
git clone <repository-url>
cd todo-microservices

# Create environment file
cp .env.docker .env

# Build and run all services
docker-compose up -d

# Application will be available at:
# - Frontend: http://localhost
# - User Service: http://localhost:3001
# - Todo Service: http://localhost:3002

Option 2: Local Development Setup

Step 1: Clone the Repository

git clone <repository-url>
cd todo-microservices

Step 2: Setup MySQL Databases

-- Login to MySQL
mysql -u root -p

-- Create databases
CREATE DATABASE IF NOT EXISTS userdb;
CREATE DATABASE IF NOT EXISTS tododb;

-- Create users
CREATE USER IF NOT EXISTS 'userservice'@'localhost' IDENTIFIED BY 'userpass123';
CREATE USER IF NOT EXISTS 'todoservice'@'localhost' IDENTIFIED BY 'todopass123';

-- Grant privileges
GRANT ALL PRIVILEGES ON userdb.* TO 'userservice'@'localhost';
GRANT ALL PRIVILEGES ON tododb.* TO 'todoservice'@'localhost';
FLUSH PRIVILEGES;

EXIT;

Step 3: Setup and Run Services

# User Service
cd user-service
npm install
cp .env.example .env  # Edit with your config
npm run dev

# Todo Service (new terminal)
cd todo-service
npm install
cp .env.example .env  # Edit with your config
npm run dev

# Frontend (new terminal)
cd frontend
npm install
cp .env.example .env  # Edit with your config
npm start

🐳 Docker Deployment

Production Deployment

# Build and start all services
docker-compose up -d

# View logs
docker-compose logs -f

# Stop all services
docker-compose down

# Rebuild after code changes
docker-compose up -d --build

Development with Hot Reload

# Use development compose file
docker-compose -f docker-compose.dev.yml up

# Services will auto-reload on code changes

Docker Commands Reference

# Build images
docker-compose build

# Start services in background
docker-compose up -d

# View running containers
docker-compose ps

# View logs for specific service
docker-compose logs -f user-service

# Execute command in container
docker-compose exec user-service sh

# Stop and remove everything
docker-compose down -v

# Rebuild specific service
docker-compose up -d --build user-service

Using Makefile

make help        # Show available commands
make build       # Build all images
make up          # Start all services
make down        # Stop all services
make logs        # View logs
make test        # Run all tests
make clean       # Clean up everything

🧪 Testing

Test Coverage Summary

User Service: 20 test cases covering authentication

Todo Service: 34 test cases covering CRUD operations

Total Coverage: >90% code coverage

Running Tests

All Tests

# User Service
cd user-service
npm test

# Todo Service
cd todo-service
npm test

Test Categories

# Unit tests only
npm run test:unit

# Integration tests only
npm run test:integration

# Tests with coverage report
npm run test:coverage

# Tests in watch mode
npm run test:watch

Test in Docker

# Run tests in Docker containers
docker-compose exec user-service npm test
docker-compose exec todo-service npm test

# Or use Makefile
make test

Test Database Setup

-- Create test databases
CREATE DATABASE IF NOT EXISTS test_userdb;
CREATE DATABASE IF NOT EXISTS test_tododb;

-- Grant permissions
GRANT ALL PRIVILEGES ON test_userdb.* TO 'root'@'localhost';
GRANT ALL PRIVILEGES ON test_tododb.* TO 'root'@'localhost';
FLUSH PRIVILEGES;

Test Examples

User Registration Test

it('Should register a new user with valid credentials', async () => {
  const response = await request(app)
    .post('/api/auth/register')
    .send({
      email: 'test@example.com',
      password: 'Test123'
    })
    .expect(201);

  expect(response.body.success).toBe(true);
  expect(response.body.data).toHaveProperty('token');
});

Todo CRUD Test

it('Should create a todo for authenticated user', async () => {
  const response = await request(app)
    .post('/api/todos')
    .set('Authorization', `Bearer ${validToken}`)
    .send({ content: 'Test todo' })
    .expect(201);

  expect(response.body.data.content).toBe('Test todo');
});

📚 API Documentation

Base URLs

User Service: http://localhost:3001

Todo Service: http://localhost:3002

Authentication Flow

sequenceDiagram
    Client->>User Service: POST /api/auth/login
    User Service-->>Client: JWT Token
    Client->>Todo Service: GET /api/todos (with JWT)
    Todo Service->>Todo Service: Validate JWT
    Todo Service-->>Client: Todo List

Endpoints Summary

User Service

Method Endpoint Description Auth Required POST /api/auth/register Register new user No POST /api/auth/login Login user No GET /health Health check No

Todo Service

Method Endpoint Description Auth Required POST /api/todos Create todo Yes GET /api/todos Get all todos Yes GET /api/todos/:id Get single todo Yes PUT /api/todos/:id Update todo Yes DELETE /api/todos/:id Delete todo Yes GET /health Health check No

Postman Collection

Import the complete Postman collection from api-docs/postman-collection.json for easy API testing.

Example Requests

curl -X POST http://localhost:3001/api/auth/register \
  -H "Content-Type: application/json" \
  -d '{"email": "user@example.com", "password": "Test123"}'

Create Todo

curl -X POST http://localhost:3002/api/todos \
  -H "Content-Type: application/json" \
  -H "Authorization: Bearer YOUR_JWT_TOKEN" \
  -d '{"content": "Complete project"}'

🔧 Environment Variables

User Service (.env)

NODE_ENV=development
PORT=3001
DB_HOST=localhost
DB_PORT=3306
DB_USER=userservice
DB_PASSWORD=userpass123
DB_NAME=userdb
JWT_SECRET=your-super-secret-jwt-key
JWT_EXPIRES_IN=24h
ALLOWED_ORIGINS=http://localhost:3000

Todo Service (.env)

NODE_ENV=development
PORT=3002
DB_HOST=localhost
DB_PORT=3306
DB_USER=todoservice
DB_PASSWORD=todopass123
DB_NAME=tododb
JWT_SECRET=your-super-secret-jwt-key  # Must match User Service
ALLOWED_ORIGINS=http://localhost:3000

Frontend (.env)

REACT_APP_USER_SERVICE_URL=http://localhost:3001
REACT_APP_TODO_SERVICE_URL=http://localhost:3002

Docker Environment (.env.docker)

# MySQL
MYSQL_ROOT_PASSWORD=rootpass123

# Services
NODE_ENV=production
JWT_SECRET=your-super-secret-jwt-key
JWT_EXPIRES_IN=24h

# Ports
USER_SERVICE_PORT=3001
TODO_SERVICE_PORT=3002
FRONTEND_PORT=80

🐛 Troubleshooting

Common Issues and Solutions

Docker Issues

Container won't start:

# Check logs
docker-compose logs service-name

# Rebuild from scratch
docker-compose down -v
docker-compose up --build

Database connection fails:

# Wait for MySQL to be ready
docker-compose exec mysql-db mysqladmin ping -h localhost

# Check database exists
docker-compose exec mysql-db mysql -u root -prootpass123 -e "SHOW DATABASES;"

Testing Issues

Tests failing with "Field 'uuid' doesn't have a default value":

# Ensure test database has correct schema
npm run test:setup

# Or manually sync schema
npm run typeorm schema:sync

JWT token mismatch:

Ensure both services use the same JWT_SECRET

Check token expiration time

Development Issues

CORS errors:

// Update ALLOWED_ORIGINS in .env
ALLOWED_ORIGINS=http://localhost:3000,http://localhost:8080

// Restart services after change

Port already in use:

# Find and kill process
lsof -i :3001  # Mac/Linux
kill -9 <PID>

# Or change port in .env
PORT=3003

Development Guidelines

Write tests for all new features

Maintain >80% code coverage

Follow TypeScript best practices

Use ESLint and Prettier for code formatting

Update documentation for API changes

👥 Authors

Ahmad Anis - Initial work and architecture

🙏 Acknowledgments

Built as a technical challenge demonstrating microservices architecture

Implements industry best practices for Node.js and React development

Features comprehensive test coverage and Docker containerization

Follows RESTful API design principles

Implements proper authentication and authorization with JWT

📊 Project Status

✅ Core functionality complete

✅ Docker containerization implemented

✅ Comprehensive test suite (54+ test cases)

✅ Production-ready with security best practices

🚧 CI/CD pipeline (optional enhancement)

🚧 Kubernetes deployment (future enhancement)

Happy Coding! 🚀

For questions or support, please open an issue in the repository.

Like this project

Posted Aug 12, 2025

Developed a microservices-based todo app with Node.js, React, and Docker.

Likes

Views
