Expose Local RTSP to HLS Stream via Cloudflare Tunnel

This project converts an RTSP camera stream to HLS (HTTP Live Streaming) and exposes it online using a Cloudflare Tunnel.

Prerequisites

Node.js and npm/yarn installed

FFmpeg installed globally on your system

Cloudflare account with access to Zero Trust Tunnels

cloudflared CLI tool installed

Setup & Usage

1. Install Dependencies

yarn install
# or
npm install

Verify that FFmpeg is installed:

ffmpeg -version

2. Configure Your RTSP URL

Open package.json

Find the convert script

Replace the placeholder rtsp://<YOUR_RTSP_URL_HERE> with your actual RTSP camera URL

3. Convert RTSP to HLS

Run the conversion script to generate HLS files:

yarn convert

This will generate HLS files in the videos/ipcam/ directory.

4. Start the Local HTTP Server

Serve the HLS files locally with CORS support:

yarn read-server

The server will run on http://localhost:8080 by default.

5. Expose via Cloudflare Tunnel

Go to Cloudflare Dashboard → Zero Trust → Tunnels

Select your tunnel or create a new one

Click Run Tunnel and copy the token

Run the tunnel locally:

cloudflared tunnel run --token <YOUR_TOKEN>

6. Access Your Stream

Once everything is running, access your HLS stream via the Cloudflare tunnel URL:

https://<your-tunnel-hostname>/index.m3u8

Project Structure

.
├── videos/
│   └── ipcam/          # HLS output files (.m3u8, .ts segments)
├── package.json        # Project scripts and dependencies
└── README.md           # This file

Notes

HLS files are stored in videos/ipcam/

Using --token is suitable for temporary sessions

For persistent tunnels, configure config.yml with credentials JSON

Ensure the Cloudflare tunnel points to the correct local HTTP server port (default: 8080)

Keep the yarn convert and yarn read-server processes running simultaneously

Troubleshooting

FFmpeg not found: Install FFmpeg and ensure it's in your system PATH

Port already in use: Change the port in your server configuration

Stream not accessible: Verify both the conversion script and HTTP server are running

Cloudflare tunnel issues: Check your tunnel configuration and token validity

License

This project is open source and available under the MIT License.
