A chat-based design layout transformation tool powered by LLM reasoning. Users interact with a design layout through natural language — saying things like "Convert this to 9:16" or "Make the headline smaller" — and the layout JSON and wireframe preview update in real-time. The agent understands semantic roles ("the headline", "the product image", "the discount badge") and translates human intent into precise coordinate transformations.

Live Demo: layout-agent-production.up.railway.app

Node.js 18+ (tested on v22)

npm 8+

LLM API key — one of the following (see Multi-Provider Support below):

Open http://localhost:5173 in your browser.

Type natural language commands in the chat panel. The wireframe and JSON update after each response.

Command What Happens Convert this to 9:16 Resizes artboard from 1080×1080 to 1080×1920, reflows all elements Move the headline to the top Repositions the "Luxury Comfort" text to the top of the canvas Make the headline smaller Reduces headline font size and bounding box proportionally Change the headline color to red Updates headline text color — visible in the wireframe Move the offer badge higher Shifts the "Limited time offer" CTA upward Make the discount badge bigger Scales both the yellow circle and "20% OFF" text together Center the product Moves the product image to the center of the canvas Make it bigger Follow-up — understands "it" from the previous command's context

Be specific or be vague — both work. "Set headline ny to 0.05" and "put the title at the top" do the same thing.

Follow-ups work — after any command, say "make it bigger", "undo that", or "move it left" and the agent knows what "it" refers to.

Reset anytime — click the "Reset Layout" button to return to the original design.

Layer Technology Purpose Frontend React 18 + Vite 6 Component rendering, hot reload Styling Tailwind CSS 3 Dark theme UI, responsive layout HTTP Client Axios API calls with 60s timeout Backend Node.js + Express API proxy, keeps LLM keys server-side LLM Groq (Llama 3.1 8B) Semantic reasoning — identifies elements, interprets intent State React useState Layout JSON + chat history (no external state library) Deployment Railway Single-URL production hosting

This project was tested across multiple LLM providers during development. Switching providers requires changing only one file (server/services/llmService.js) — the API URL, model name, and auth header.

Provider Model Cost Speed JSON Reliability Notes Groq Llama 3.1 8B Instant Free (generous limits) ~200ms Good with prompt tuning Current default. 30 req/min, 100K tokens/day free Groq Llama 3.3 70B Free ~800ms Better reasoning Higher quality but burns through daily token limit 4× faster Anthropic Claude Sonnet 4 ~$3/M input tokens ~2-4s Excellent Best JSON accuracy, but requires paid API key Anthropic Claude Haiku 3.5 ~$0.25/M input ~1s Very good Good balance of cost and quality OpenRouter Any model via proxy Varies Varies Varies Useful for accessing multiple providers with one key

Rate limiting was the most operationally challenging aspect of this project. Each provider handles it differently, and getting it wrong means a broken user experience.

Groq enforces three limits simultaneously: requests per minute (30 RPM), tokens per minute (6,000 TPM for free tier), and tokens per day (100,000 TPD). The daily limit is the one that bites — during development, the 70B model consumed ~2,500 tokens per request (system prompt + response), meaning roughly 40 requests before hitting the wall. Switching to the 8B model cut usage to ~800 tokens per request, giving ~125 requests per day. The server implements automatic retry with backoff: on a 429 response, it parses the Retry-After header, waits, and retries up to 3 times transparently.

OpenRouter uses a credit-based system. The most common failure mode is requesting more max_tokens than your balance can cover — the API returns a 402 with the exact number of tokens you can afford. This required progressively lowering max_tokens from 8192 → 2048 → 1024 during testing. The diff-based architecture (see APPROACH.md) was partly motivated by this constraint: smaller responses = cheaper requests = more testing budget.

Anthropic is the most straightforward — standard RPM/TPM limits with clear error messages. The main challenge is cost: sending the full layout JSON (~3,000 tokens) in every request adds up. The system prompt optimization that compresses the layout into a ~500 token summary reduced per-request cost by roughly 60%.

The retry logic lives in fetchWithRetry() in llmService.js and handles all providers uniformly since they all use standard HTTP status codes.

The server serves both the API and the built React frontend from a single process, so one deployment = one URL.

Push to GitHub

Go to railway.app → New Project → Deploy from GitHub

Add variable: GROQ_API_KEY = your key

Railway auto-detects railway.toml and deploys

Push to GitHub

Go to render.com → New Web Service → connect repo

Build command: cd client && npm install && npm run build && cd ../server && npm install

Start command: cd server && node index.js

Add env var: GROQ_API_KEY

MIT
