Smart Form Validator

A highly customizable, "somewhat" declarative approach to HTML form fields validation.

Installation

Using npm:

npm install smart-form-validator --save

Later in our code:

import SmartFormValidator from "smart-form-validator"; // Or if you prefer: // const SmartFormValidator = require("smart-form-validator");

Using jsDelivr CDN:

SmartFormValidator is now available as a property of the global object.

Using unpkg CDN:

SmartFormValidator is now available as a property of the global object.

Applying default effects styles

To get the default effects styles applied to our form fields, we need to add the CSS file to our page.

Using jsDelivr CDN:

Using unpkg CDN:

Quick start

1. Using regular script tag:

<html> <head> <link href="https://cdn.jsdelivr.net/npm/smart-form-validator/dist/css/smart-form-validator.min.css" rel="stylesheet" /> <script src="https://unpkg.com/smart-form-validator/dist/smart-form-validator.min.js"></script> </head> <body> <form id="signup-form"> <input type="text" id="name-field" /> <input type="email" id="email-field" /> <button role="submit-button">Sign up</button> </form> <script> const form = document.getElementById("signup-form"); new SmartFormValidator() .addForm(form) .addRule({ field: "name-field", type: "ascii", length: { min: 3, max: 10 } }) // expects only ASCII strings between 3 to 10 characters long .addRule({ field: "email-field", type: "email" }) // expects only valid email formats .watch(); // watch the input fields for changes, ensuring that they adhere to the specified constraints </script> </body> </html>

2. Using as an ES Module:

// File: signup-form-validator.js // If you've installed smart-form-validator using `npm install smart-form-validator` import SmartFormValidator from "smart-form-validator"; // Otherwise, // import SmartFormValidator from "https://unpkg.com/smart-form-validator/dist/esm/smart-form-validator.js"; const form = document.getElementById("signup-form"); new SmartFormValidator() .addForm(form) .addRule({ field: "name-field", type: "ascii", length: { min: 3, max: 10 } }) // expects only ASCII strings between 3 to 10 characters long .addRule({ field: "email-field", type: "email" }) // expects only valid email formats .watch(); // watch the input fields for changes, ensuring that they adhere to the specified constraints

The idea behind Smart Form Validation is simple. A form has input fields; Each field has conditions and constraints that data entered into it must satisfy to be considered valid. When a field receives input from a user, our code validates the input value to ensure that it satisfies the constraints placed on that field. Acting on the result of that check, some form of state change may be effected on the input element or the entire form, letting the user know whether or not they have entered the expected type of value in the field before they even attempt to submit the form for processing. In some cases, we may even limit their ability to submit the form if they have entered incorrect values into one or more of the form fields.

Smart Form Validation inserts a semantic boundary between these ideas by "separating" them into fields (receptors of user values), rules (constraints on fields), validators (checks that ensure that a field's value adheres to the constraints placed on that field), and effects (state changes on a form field that give the user (instant) feedback regarding the value they have entered into the field).

Concepts (summary)

Fields: Fields are elements that can receive user input. They represent the objects we want to validate.

Rules: Rules specify constraints on fields. They state the conditions that field values must fulfill to be valid.

Validators: Validators check that data entered into fields comply with the rules specified for those fields.

Effects: Effects are actions that perform state changes on fields based on the results of validation.

Concepts (details)

1. Fields

A field is a receptor of user data and is the subject of validation. A field can be any HTML element capable of receiving user input such as input, checkbox, textarea, select, and contenteditable elements. A field must have an id property. A field may optionally have a role and getValue properties.

If we have a button or input whose type is not submit but on which we want effects that handle submit buttons to have access, a role attribute with the value of submit-button is required for that field.

The getValue property, if provided, must be a function. This function is used to get the current value of the field if the field is not a contenteditable field and is not one of input, checkbox, textarea, or select.

The state of a field changes in response to the data entered and its adherence to the constraints or rules defined for/placed on that field.

2. Rules

A rule is an object that specifies the constraint(s) on a field. It encapsulates the constraints we want placed on that field. For any field to be validated, we must attach a rule with at least one constraint to it.

Rules are plain JavaScript objects with one required property: field. The value of the field can be either the element's id or, in instances where we have previously obtained a reference to the element, the element reference.

Other properties of a rule depend on the type of the field, and specify the constraints we want placed on the field.

Default constraints

The current default supported constraints are:

type {String}: specifies the acceptable data type of the value for this field, one of either ("alnum"|"alpha"|"ascii"|"email"|"number"). Default is alnum.

required {Boolean}: specifies whether the field is required (true) or not (false).

length {Number|Object}: specifies the accepted (minimum or maximum or both) input length. If the value is a number, it specifies the maximum length. If the value is an object, it specifies. the minimum and/or maximum length:

matchCase {Boolean}: performs a case-sensitive (true) or case-insensitive (false) validation.

allowWhitespace {Boolean}: specifies whether the field allows whitespace values or not.

regex {Object|String}: specifies a custom validation regex. This can be a regex string or regex object.

To specify that a field accepts only numbers that are between 3 to 7 characters, for example, we'd create a rule with the following constraints:

const rule = { field: someFieldRefOrItsId, type: "number", length: { min: 3, max: 7 } }; new SmartformValidator() .addForm(form) .addRule(rule)

Note: We can create custom rules and write custom validators that check for these rules. See the the section on Customizing Smart Form Validator for more.

3. Validators

Validators are like rule "enforcers". A validator is a function that checks that the data entered into a field complies with the constraints placed on that field.

Default validators

The following validators come built-in corresponding with the default constraints:

alphaValidator: checks that a field contains only the letters A - Z, underscores (_), and dashes (-). The field can also accept whitespace characters with the allowWhitespace constraint set to true. To perform a case-insensitive check, set the matchCase constraint to false.

alphanumericValidator: checks that a field contains only the letters A - Z, the numbers 0 - 9, underscores (_), and dashes (-). The field can also accept whitespace characters with allowWhitespace set to true. To perform a case-insensitive check, set matchCase to false.

asciiTextValidator: checks that a field contains only characters from the ASCII character-set. This validator accepts whitespace characters by default irrespective of the value of allowWhitespace. However, we can specify a case-insensitive match by setting matchCase to false.

emailValidator: checks that the value entered into the field has a valid email format.

lengthValidator: checks that the value entered in the field is between the minimum and/or maximum specified length.

numberValidator: checks that a field contains only the numbers 0 - 9. The field can also accept whitespace characters with allowWhitespace set to true.

regexValidator: checks that a field's value conforms to a custom regular expression constraint.

requiredFieldValidator: checks that a field has some data entered into it.

Notes

For a custom constraint to be checked during validation, there must be a corresponding validator defined for it.

We can create custom validators that make use of the default constraints or that define their own rules. See the Creating custom validators section for more on how to do this.

4. Effects

An Effect represents an action to be taken based on the outcome of a field's validation. We can, for example, use an effect to display hints to the user as they input data into a field, to disable the submit button and prevent the form from being submitted unless every other field has valid input, or to add some special CSS effects to a field to indicate its state as either valid or invalid.

Having dedicated effect handlers helps reduce the surface area for surprises arising from side-effects during form validation.

Note: As with rules and validators, we can create and register custom effects that can be applied for when a field is either valid or invalid. The section on Creating custom effects goes into details on how to do this.

Customizing Smart Form Validator

Smart Form Validator is easy to customize. To customize Smart Form Validator, we just need to, as already stated:

(optionally) create custom constraints.

create custom validators for to check for custom constraints created by us or other third-parties, or for any of the default-supported constraints.

(optionally) create custom effects to respond to the result of validation from either our own custom validator(s) or the default validators.

Creating custom validators

A validator is a function that is called to, well... validate the data entered into a field. The validator function is passed the following positional arguments in order:

value: the data entered by the user into the field.

rule: an object containing the constraints specified for that field. The validator checks that the value adheres to the rule.

prevResult: a boolean value that tells the current validator the result of the previous validator in the chain of validators attached to this field.

extras: an object containing any extra information. A checkbox, for example, can have the value on or off and a checked state that can be either true or false. The value (on or off) will be passed as the first argument (the value argument) to the validator. The checked state will be passed in as extras.checked.

A validator should return true if the field it is validating passed the validation rule. Otherwise it should return false.

Registering validators

After creating a validator, we must register it with the addValidator method of the SmartFormValidator instance.

addValidator takes three ordered arguments:

name {String} (required): an arbitrary string that can serve as a unique name for the validator.

validator {Function} (required): the validator function itself.

meta {Object} (optional): an object that holds meta information about the validator. To prevent naming conflict with other validators, we can have a meta.namespace property. This property should be a string. This string is used in conjunction with the validator name to create a unique name for the validator.

Tips and best practices for writing validators.

Validators should aim at being focused and specific. A validator should deal with just one aspect of the constraints on a field rather than attempting to determine if every constraint on the field has been met. For example, instead of having a validator that checks for a required state, a maximum length constraint, and whether or not the field contains numbers, it's better to have separate validators for each of these checks: one to check for required, another to ensure the length constraint is met, and yet another to check that the number constraint is fulfilled. Each of these validators will be called with the rule and the result of the previous validator.

A validator should return only true or false values. A validator should not throw errors nor otherwise perform a side-effect on a field in the event of a successful or failed validation. Any such effects should be delegated to effects.

Creating custom effects

Every effect is a plain JavaScript object with the following required properties:

name {String}: the effect name is an arbitrary string used to uniquely identify the effect.

valid{Function}: a function to be invoked to handle the case when the field passes validation. The function is passed the field as the first argument.

invalid {Function}: a function to be called to handle the case when the field fails validation. The function is passed the field as the first argument.

An effect object may also contain the following optional properties:

init {Function}: an initialization function that is called to perform any initialization tasks for the effect. This function is called once when the effect is registered.

meta {Object}: an object that holds meta information (such as author, version, etc) about the effect. A recommended property is meta.namespace that helps to prevent naming conflict with other effects. This property expects a string value that is used in conjunction with the effect name property to create a unique name for the effect.

Registering effects

After creating an effect, we must register it for it to be applied during form validation. An effect can be registered "globally" or "locally".

Registering an effect "globally" makes the effect available to all instances of SmartFormValidator. Just call useEffect(effect) statically on the SmartFormValidator class like so: SmartFormValidator.useEffect(effect).

Registering an effect "locally" means the effect is only available to fields managed by the SmartFormValidator instance on which useEffect is called. To do a "local" effect registration, call the useEffect(effect) method on an instance. For example:

const validator = new SmartFormValidator(); validator.useEffect(effect);

In both cases, useEffect expects the complete effect object as its argument.

Customizing Smart Form Validator - A quick example

Say we have a field and we want to define a constraint on that field so that it only accepts objects (or JSON strings). First, we'd create a rule stating that requirement. The rule should have a field property that specifies the target field. However, we may omit this property while creating the rule, but must specify it when adding the rule to the field.

const objectExpectedRule = { type: "object" };

Next, we need to add the rule to the field:

const fieldId = "someArbitraryIdentifier"; const validator = new SmartFormValidator(); // register the field on the validator, specifying the rule, // this can be done in several ways // (the first two are useful if the field is a stand-alone field, // the last is useful when the field is part of a form): // 1. validator.addField(fieldId, objectExpectedRule); // specify field and rule at the same time, on one line // Or ... // 2. // validator.addField(fieldId); // register the field // validator.addRule({ ...objectExpectedRule, field: fieldId }); // add the rule to the field. // Or, if the field is part of a form // 3. // validator.addForm(form) // .addField(fieldId, objectExpectedRule);

Next, we'll create a custom validator to check that the field complies with this constraint:

Finally, we need to register our validator so it can be invoked during the validation process:

const validatorName = "objectValidator"; const validatorFunc = objectValidator; const validatorMeta = { // optional but recommended namespace: "some-namespace", version: 1.0.0 }; validator.addValidator(validatorName, validatorFunc, validatorMeta);

Running the examples

Run npm run examples

Navigate to localhost:8080/examples

Contributing

Report a bug

Request a new feature

Submit a pull request

Checkout the Contributing guide

CHANGELOG

See CHANGELOG

License

MIT License

Author

Simplymichael (simplymichaelorji@gmail.com)

Release process (manual)

Checkout main branch: git checkout main.

Merge latest changes from develop into main branch: git merge develop.

Build: npm run build.

Stage build: git add dist.

Commit build: git commit -m ":rocket: Build latest version".

Run release script: npm run release:[major|minor|patch].

Inspect the CHANGELOG.md file and make any necessary adjustments.

Inspect the package.json file (package.json.version) and make any necessary adjustments.

Stage changes: git add CHANGELOG.md package*.json

Commit CHANGELOG update and version number bump: git commit -m ":books: Update CHANGELOG.md, and :package: bump version number from <prev_ver> to <curr_ver>".

Tag build: git tag -a vx.x.x -m ":bookmark: <tag summary>".

Push to github: git push && git push origin --tags.

Draft release on GitHub (optional).

Publish to NPM: npm publish.

Checkout develop branch: git checkout develop.

Merge updates from main branch into develop: git merge main.
