ARM64 Bare Metal Memory Allocator

A custom memory allocator implementation for ARM64 bare-metal systems, featuring a minimal operating system kernel with UART communication and interactive shell.

Overview

This project implements a complete bare-metal system that includes:

Custom Memory Allocator: A heap-based memory management system with block splitting and coalescing

ARM64 Kernel: Minimal kernel that boots on ARM64 hardware/emulation

UART Communication: Serial communication for input/output

Interactive Shell: Command-line interface for testing the allocator

Linker Script: Custom memory layout for bare-metal execution

Features

Memory Allocator

Dynamic allocation: malloc-like functionality with my_malloc()

Memory deallocation: free-like functionality with my_free()

Block splitting: Efficiently splits large blocks when allocating smaller sizes

Block coalescing: Merges adjacent free blocks to prevent fragmentation

Alignment: All allocations are aligned to 8-byte boundaries

Debug information: Real-time memory statistics and block visualization

System Features

Bare-metal kernel: No operating system dependencies

UART I/O: Full serial communication stack

Interactive shell: Real-time testing environment

Memory safety: Double-free detection and error handling

Project Structure

my_allocator/
├── allocator.c      # Memory allocator implementation
├── allocator.h      # Allocator header and interface
├── boot.S          # ARM64 assembly boot code
├── kernel.c        # Main kernel and shell implementation
├── uart.c          # UART driver implementation
├── uart.h          # UART driver header
├── linker.ld       # Linker script for memory layout
├── Makefile        # Build configuration
└── README.md       # This file

Prerequisites

macOS

# Install ARM64 cross-compilation toolchain
brew install --cask gcc-aarch64-embedded

# Install QEMU emulator
brew install qemu

Linux (Ubuntu/Debian)

# Install ARM64 cross-compilation toolchain
sudo apt-get install gcc-aarch64-linux-gnu

# Install QEMU
sudo apt-get install qemu-system-arm

Building and Running

Build the Kernel

# Clean previous builds
make clean

# Compile the kernel
make

# This creates kernel8.img - the bootable kernel image

Run in QEMU

# Run the kernel in ARM64 emulation
make run

# Alternative: Run QEMU directly
qemu-system-aarch64 -M virt -cpu cortex-a53 -nographic -kernel kernel8.img

Exit QEMU

To exit the emulator, press: Ctrl+A then X

Usage

Once the kernel boots, you'll see:

===================================
ARM64 Bare Metal Memory Allocator
===================================

Memory allocator initialized
Heap start: 0x40081000
Heap end: 0x40181000
Total heap size: 1048552 bytes

Shell ready. Available commands:
  alloc <size> - Allocate memory of <size> bytes
  free <addr> - Free memory at address <addr>
  info - Display memory allocator information
  help - Display this help message

>

Available Commands

alloc <size>

Allocates memory of the specified size in bytes.

> alloc 100
Allocated 100 bytes at address: 0x40081018

free <address>

Frees memory at the specified hexadecimal address.

> free 0x40081018
Memory freed at address: 0x40081018

info

Displays detailed memory allocator statistics and block information.

> info
Memory Allocator Info:
  Total heap size: 1048552 bytes
  Total allocated: 100 bytes
  Total free: 1048452 bytes
Memory blocks:
  Block 0: Address=0x40081000, Size=100, Status=USED
  Block 1: Address=0x40081080, Size=1048452, Status=FREE

help

Shows all available commands and their usage.

Memory Management Details

Allocation Algorithm

Size Alignment: All allocations are aligned to 8-byte boundaries

First Fit: Searches for the first free block large enough

Block Splitting: Splits blocks when they're significantly larger than needed

Metadata: Each allocated block has a header containing size and status information

Deallocation Algorithm

Validation: Checks for double-free attempts

Status Update: Marks block as free and updates statistics

Coalescing: Merges with adjacent free blocks to reduce fragmentation

Memory Layout

Heap Memory Layout:
[Block Header][User Data][Block Header][User Data]...

Block Header Structure:
- size: Size of the user data area
- is_free: 1 if free, 0 if allocated
- next: Pointer to next block

Technical Details

Architecture

Target: ARM64 (AArch64) Cortex-A53

Memory Model: 1MB heap starting at 0x40081000

Alignment: 8-byte alignment for all allocations

Endianness: Little-endian

Compilation Flags

-ffreestanding: Bare-metal compilation

-nostdinc -nostdlib -nostartfiles: No standard library dependencies

-mcpu=cortex-a53: Target ARM Cortex-A53 processor

-Wall -O2: Warnings enabled, optimization level 2

Linker Configuration

The linker.ld script defines:

Code placement in memory

Stack location

Heap boundaries (heap_start and heap_end symbols)

Testing Examples

Basic Allocation Test

> alloc 64
Allocated 64 bytes at address: 0x40081018

> alloc 128
Allocated 128 bytes at address: 0x40081068

> info
Memory Allocator Info:
  Total heap size: 1048552 bytes
  Total allocated: 192 bytes
  Total free: 1048360 bytes

Fragmentation Test

> alloc 100
> alloc 200
> free 0x40081018  # Free the first block
> alloc 50         # Should reuse the freed space
> info             # Check memory layout

Error Handling Test

> free 0x40081018
> free 0x40081018  # Try to free the same address again
Error: Double free detected

Development

Adding New Features

New Commands: Add cases to the command parser in kernel.c

Allocator Features: Extend functions in allocator.c

I/O Functions: Add UART utilities in uart.c

Debugging

Use info command to inspect memory state

UART output provides real-time feedback

QEMU monitor commands available with Ctrl+A, C

Performance Characteristics

Time Complexity

Allocation: O(n) where n is the number of blocks

Deallocation: O(1) for marking free, O(1) for simple coalescing

Memory info: O(n) for traversing all blocks

Space Complexity

Overhead: sizeof(block_header_t) bytes per allocated block

Alignment: Up to 7 bytes padding per allocation

Fragmentation: Minimal due to coalescing strategy

Limitations

Single-threaded: No concurrency support

No advanced coalescing: Only merges with next block

Fixed heap size: 1MB heap defined at compile time

No garbage collection: Manual memory management only

Contributing

Fork the repository

Create a feature branch

Test changes in QEMU

Submit a pull request

License

This project is provided as educational material for understanding bare-metal systems programming and memory management.

Built for ARM64 bare-metal systems • Tested on QEMU ARM64 emulation
