Swivel Bearing Assembly – CATIA V5
Created a 3D swivel bearing assembly in CATIA V5 from a technical reference drawing. I interpreted the 2D drawing, modeled the individual mechanical components, and assembled them into a complete 3D model.
This project demonstrates my ability to interpret engineering drawings and convert them into structured 3D CAD assemblies.
