The objective was to transform an early prototype made from wood and steel into a fully updated design constructed entirely from HSS and steel plate brackets.

Using CAD software, I created a 3D printable model of the cup holder based on reference images and dimensions provided.

I design a case that fits the Orange Pi Zero 2, replicates the look of the Nintendo 64 console, and is compatible with most general 3D printing.

The goal was to design a Frame assembly drawing for a trailer screen. Built a 3D frame model, and created a detailed drawing with dimensions and multiple views.

The goal was to clearly illustrate the areas where the holder would fold, the placement of the cup holders, and how the ends click into place during assembly.
