This project showcases a comprehensive G+1 residential architectural layout designed with a strong focus on functional space planning, efficient circulation, and structural detailing.
Key Project Features:
Ground Floor Plan: Features an optimized residential layout complete with an integrated kitchen, spacious dining and living zones, multiple bedrooms with built-in wardrobes, and dedicated utility/washroom spacing.
First Floor Plan: Comprises a multi-bedroom arrangement configured with private balconies, functional lounge/sitting spaces, and a mirrored vertical circulation layout via an efficiently placed dog-legged staircase.
Technical Specifications: Developed in accordance with standard civil engineering drafting metrics. The layout incorporates standard structural guidelines including a minimum 2'0'' plinth level height above road level, defined reinforcement clear cover provisions 40mm for columns, 25mmfor beams/slabs), and standardized 5'' internal partition walls paired with load-bearing external walls.
Design EngineeringAutoCAD
